343
Ste
p
Command
Remarks
1. Enter system view. system-view N/A
2. Enter IPv6 PIM view.
pim ipv6 N/A
3. Disable the BSM semantic
fragmentation function.
undo bsm-fragment enable
By default, the BSM semantic
fragmentation function is enabled.
Configuring IPv6 administrative scoping
When administrative scoping is disabled, an IPv6 BIDIR-PIM domain has only one BSR. The BSR
manages the whole network. To manage your network more effectively and specifically, you can divide
the IPv6 BIDIR-PIM domain into multiple admin-scope zones. Each admin-scope zone maintains a BSR,
which serves a specific multicast group range. The global scope zone also maintains a BSR, which serves
all the rest multicast groups.
Enabling IPv6 administrative scoping
Before you configure an IPv6 admin-scope zone, you must enable IPv6 administrative scoping first.
Perform the following configuration on all routers in the IPv6 PIM-SM domain.
To enable IPv6 administrative scoping:
Ste
p
Command
Remarks
1. Enter system view.
system-view N/A
2. Enter IPv6 PIM view. pim ipv6 N/A
3. Enable IPv6 administrative
scoping.
c-bsr admin-scope Disabled by default.
Configuring an IPv6 admin-scope zone boundary
The boundary of each IPv6 admin-scope zone is formed by ZBRs. Each admin-scope zone maintains a
BSR, which serves a specific IPv6 multicast group range. IPv6 multicast packets (such as assert messages
and bootstrap messages) that belong to this range cannot cross the admin-scope zone boundary.
Perform the following configuration on routers that you want to configure as a ZBR.
To configure an admin-scope zone boundary:
Ste
p
Command
Remarks
1. Enter system view.
system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure an IPv6 multicast
forwarding boundary.
multicast ipv6 boundary
{ ipv6-group-address prefix-length |
scope { scope-id | admin-local |
global | organization-local |
site-local } }
By default, no IPv6 multicast
forwarding boundary is
configured.
