351
Ste
p
Command Remarks
6. Configure the join/prune
timeout timer.
pim ipv6 holdtime join-prune
interval
Optional.
210 seconds by default.
7. Configure assert timeout
timer.
pim ipv6 holdtime assert interval
Optional.
180 seconds by default.
Configuring join/prune message sizes
A large size of a join/prune message might result in loss of a larger amount of information if a message
is lost. You can set a small value for the maximum size of each join/prune message to reduce the impact
in case of the loss of a message.
By controlling the maximum number of (S, G) entries in each join/prune message, you can effectively
reduce the number of (S, G) entries sent per unit of time.
To configure join/prune message sizes:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter IPv6 PIM view.
pim ipv6 N/A
3. Configure the maximum size
of each join/prune message.
jp-pkt-size packet-size
Optional.
8100 bytes by default.
4. Configure the maximum
number of (S, G) entries in
each join/prune message.
jp-queue-size queue-size
Optional.
1020 by default.
Displaying and maintaining IPv6 PIM
Task Command Remarks
Display information about the
BSR in the IPv6 PIM-SM domain
and the locally configured
C-RPs in effect.
display pim ipv6 bsr-info [ | { begin | exclude |
include } regular-expression ]
Available in any
view.
Display information about the
IPv6 unicast routes used by IPv6
PIM.
display pim ipv6 claimed-route
[ ipv6-source-address ] [ | { begin | exclude |
include } regular-expression ]
Available in any
view.
Display the number of IPv6 PIM
control messages.
display pim ipv6 control-message counters
[ message-type { probe | register | register-stop } |
[ interface interface-type interface-number |
message-type { assert | bsr | crp | graft | graft-ack
| hello | join-prune | state-refresh } ] * ] [ | { begin
| exclude | include } regular-expression ]
Available in any
view.
Display the DF information of
IPv6 BIDIR-PIM.
display pim ipv6 df-info [ rp-address ] [ | { begin |
exclude | include } regular-expression ]
Available in any
view.
