Figure 103 Network diagram
Device Interface IPv6 address Device Interface IPv6 address
Router A GE2/1/1 1001::1/64 Router D S3/1/1 3002::2/64
S3/1
/
1 1002::1
/
64 S3/1
/
2 6001::1
/
64
Router B GE2/1/1 2001::1
/
64 POS5/1/1 6002::1
/
64
S3/1/1 1002::2/64 Router E GE2/1/1 7001::1/64
POS5/1/1 2002::1
/
64 S3/1
/
1 3003::2
/
64
POS5/1/2 2003::1
/
64 S3/1
/
2 6001::2
/
64
Router C GE2/1/1 3001::1/64 Router F S3/1/1 8001::1/64
S3/1
/
1 3002::1
/
64 POS5/1/1 6002::2
/
64
S3/1
/
2 3003::1
/
64 POS5/1/2 2003::2
/
64
POS5/1/1 2002::2/64 Router G GE2/1/1 9001::1/64
POS5/1/2 3004::1
/
64 S3/1
/
1 8001::2
/
64
Router H S3/1
/
1 4001::1
/
64 Source 1 — 2001::100/64
POS5/1/1 3004::2/64 Source 2 — 3001::100/64
Router I GE2/1/1 5001::1
/
64 Source 3 — 9001::100
/
64
S3/1
/
1 4001::2
/
64
Configuration procedure
1. Configure the IPv6 address and prefix length for each interface according to Figure 103. (Details
not shown.)
2. Configure OSPFv3 on the routers in the IPv6 PIM-SM domain to ensure network-layer reachability
among them. (Details not shown.)
3. Enable IPv6 multicast routing, IPv6 administrative scoping, IPv6 PIM-SM, and MLD:
Router A
Router B
ZBR
Router C
ZBR
Router D
ZBR
Router E
Router HRouter I
Router F
Router G
Source 3
Source 1
Source 2
Receiver
Host A
S3/1/1
S3/1/2
POS5/1/1
GE2/1/1
POS5/1/2 S3/1/1
S3/1/2
POS5/1/1
POS5/1/1
S3/1/1
S3/1/1
GE2/1/1
S3/1/1
S3/1/2
GE2/1/1
S3/1/1
S3/1/1 POS5/1/1
G
E2/1
/1
GE2/1/1 GE2/1/1
POS5/1/1
POS5/1/2 POS5/1/2S3/1/1
S3/1/1
IPv6 admin-scope 2
IPv6 PIM-SM
IPv6 global-scope
IPv6 admin-scope 1
Receiver
Host B
Receiver
Host C
