For more information about IGMP snooping, router ports, and member ports, see "Configuring IGMP
snooping." For more information about VLAN tags, see Layer 2—LAN Switching Configuration Guide.
Multicast VLAN configuration task list
Task Remarks
Configuring a sub-VLAN-based multicast VLAN
Required.
Configuring a port-based
multicast VLAN
Configuring user port attributes
Configuring multicast VLAN ports
Setting the maximum number of forwarding entries in a multicast VLAN Optional.
NOTE:
If you have configured both a sub-VLAN-based multicast VLAN and a port-based multicast VLAN on a
device, the port-based multicast VLAN configuration is given preference.
Configuring a sub-VLAN-based multicast VLAN
Before you configure a sub-VLAN-based multicast VLAN, complete the following tasks:
• Create VLANs as required.
• Enable IGMP snooping in the VLAN to be configured as a multicast VLAN.
In this approach, you first configure a VLAN as a multicast VLAN, and configure the VLANs that contain
receivers as sub-VLANs of the multicast VLAN.
When you configure a sub-VLAN-based multicast VLAN, following these guidelines:
• Do not configure a multicast VLAN on a device with IP multicast routing enabled.
• The VLAN to be configured as a multicast VLAN must exist.
• The VLANs to be configured as sub-VLANs of the multicast VLAN must exist and must not be
multicast VLANs or sub-VLANs of any other multicast VLAN.
• The total number of sub-VLANs of a multicast VLAN must not exceed the system upper limit.
To configure a sub-VLAN-based multicast VLAN:
Ste
p
Command
Remarks
1. Enter system view. system-view N/A
2. Configure the specified VLAN
as a multicast VLAN and enter
multicast VLAN view.
multicast-vlan vlan-id
By default, a VLAN is not a
multicast VLAN.
3. Configure the specified
VLANs as sub-VLANs of the
multicast VLAN.
subvlan vlan-list
By default, a multicast VLAN has
no sub-VLANs.
