R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

54
Ste
p
Command Remarks
2. Configure the maximum
number of entries in the
multicast forwarding table.
multicast forwarding-table
route-limit limit
Optional.
The default value is 4096.
3. Configure the maximum
number of downstream nodes
for a single multicast
forwarding entry.
multicast forwarding-table
downstream-limit limit
Optional.
The default value is 128.
Configuring the multicast forwarding table size in a VPN instance
Ste
p
Command Remarks
1. Enter system view.
system-view
N/A
2. Enter VPN instance view.
ip vpn-instance vpn-instance-name
N/A
3. Configure the maximum
number of entries in the
multicast forwarding table.
multicast forwarding-table
route-limit limit
Optional.
The default value is 4096.
4. Configure the maximum
number of downstream nodes
for a single route in the
multicast forwarding table.
multicast forwarding-table
downstream-limit limit
Optional.
The default value is 128.
Configuring static multicast MAC address entries
This feature is supported only on the router that is installed with the SAP module.
In Layer-2 multicast, a Layer 2 multicast protocol (such as IGMP snooping) can dynamically add multicast
MAC address entries. Multicast MAC address entries can also be manually configured.
Configuration guidelines
• When you configure a static multicast MAC address entry in system view, the configuration is
effective on the specified interfaces. When you configure a static multicast MAC address entry in
interface view or port group view, the configuration is effective only on the current interface or all
interfaces in the port group.
• Any legal multicast MAC address except 0100-5Exx-xxxx (where x represents a hexadecimal
number from 0 to F) can be manually added to the multicast MAC address table. Multicast MAC
addresses are the MAC addresses whose the least significant bit of the most significant octet is 1.
Configuring a static multicast MAC address entry in system view
Ste
p
Command Remarks
1. Enter system view.
system-view
N/A
2. Configure a static multicast
MAC address entry.
mac-address multicast
mac-address interface interface-list
vlan vlan-id
No static multicast MAC address
entries exist by default.
