When you use this command to display ACFP rule information in order of outbound/inbound interface,

if you specify no interface, the rule information for all inbound interfaces or outbound interfaces is

displayed.

Examples

# Display ACFP rule information in order of inbound interface.

<Sysname> display acfp rule-info in-interface gigabitethernet 1/0/1

In-Interface: GigabitEthernet1/0/1

ACFP rule total number: 1

ClientID:1 Policy-Index:1 Rule-Index:1

SIP:192.168.1.1 SMask:0.0.0.255

Action:redirect Status:active OperationStatus:succeeded

# Display ACFP rule information in order of policy.

<Sysname> display acfp rule-info policy 1 1

ACFP Rule total number: 1

ClientID:1 Policy-Index:1 Rule-Index:1

SIP:192.168.1.1 SMask:0.0.0.255 SPort:65500 to 65535

DIP:192.168.2.1 DMask:0.0.0.255 DPort:65500 to 65535

Protocol:ip Fragment:false DSCP:AF11

Action:redirect Status:active OperationStatus:succeeded

# Display ACFP rule information in order of global policy.

<Sysname> display acfp rule-info global

ACFP Rule total number: 1

ClientID:1 Policy-Index:1 Rule-Index:1

SIP:192.168.1.1 SMask:0.0.0.255 SPort:65500 to 65535

DIP:192.168.2.1 DMask:0.0.0.255 DPort:65500 to 65535

Protocol:ip Fragment:false ToS:6 Pre:2

TCPFlag: 010100 TCPMask:010100

Action:redirect Status:inactive OperationStatus:failed

Table 4 Command output

Field Descri

tion

In-Interface

Inbound interface of the packet.

ACFP rule total number Total number of ACFP rules.

ClientID

Client ID, index of client list.

Policy-Index Policy index.

Rule-Index

Rule index.

SMAC Source MAC address.

DMAC Destination MAC address.

StartVLAN Start VLAN of the source VLAN.

EndVLAN End VLAN of the source VLAN.

PackRate Value of the restricted rate of packets, in kbps.

SIP

Source IP address.
