R3303-HP 6600/HSR6600 Routers OAA Command Reference

30
Field Descri
p
tion
SMask Inverse mask of source IP address.
SPort Source port number.
DIP Destination IP address.
DMask Inverse mask of destination IP address.
DPort Destination port number.
Protocol Protocol of the packet, such as GRE, ICMP, IGMP, IPinIP, OSPF, TCP, UDP, or IP.
Fragment
Whether the packet is a fragment:
• true—The packet is a fragment.
• false—All packets, not concerned about whether the packet is a fragment or
not.
ToS Type of Service, indicated by a number in the range of 0 to 15.
Pre Packet precedence, indicated by a number in the range of 0 to 7.
DSCP
Differentiated Services Code Point, indicated by characters for Be, Ef, Af11,
Af12, Af13, Af21, Af22, Af23, Af31, Af32, Af33, Af41, Af42, Af43, Cs1,
Cs2, Cs3, Cs4, Cs5, Cs6, and Cs7 and indicated by a number in the range 0
to 63 for other code points.
TCPFlag
The value is six bits, which represents URG, ACK, PSH, RST, SYN, and FIN
respectively from low to high.
TCPMask
The value is six bits, which represents URG mask, ACK mask, PSH mask, RST
mask, SYN mask, and FIN mask respectively from low to high.
For each bit, the value 1 indicates that this bit is concerned, and the value 0
indicates that this bit is not concerned.
Action
Action to be taken:
• permit.
• deny.
• mirror.
• redirect.
• rate—Rate limit.
Status Rule status, active or inactive.
OperationStatus Rule application status, succeeded or failed.
display acfp server-info
Use display acfp server-info to display ACFP server information.
Syntax
display acfp server-info [ | { begin | exclude | include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
