Configuration prerequisites
Before you configure common PIM features, complete the following tasks:
• Configure any unicast routing protocol so that all devices in the domain are interoperable at the
network layer.
• Configure PIM-DM, or PIM-SM, or PIM-SSM.
• Determine the ACL rule for filtering multicast data.
• Determine the ACL rule defining a legal source address range for hello messages.
• Determine the priority for DR election (global value/interface level value).
• Determine the PIM neighbor timeout timer (global value/interface value).
• Determine the prune message delay (global value/interface level value).
• Determine the prune override interval (global value/interface level value).
• Determine the prune delay.
• Determine the hello interval (global value/interface level value).
• Determine the maximum delay between hello message (interface level value).
• Determine the assert timeout timer (global value/interface value).
• Determine the join/prune interval (global value/interface level value).
• Determine the join/prune timeout (global value/interface value).
• Determine the multicast source lifetime.
• Determine the maximum size of join/prune messages.
• Determine the maximum number of (S, G) entries in each join/prune message.
Configuring a multicast data filter
In either a PIM-DM domain or a PIM-SM domain, routers can check passing-by multicast data based on
the configured filtering rules and determine whether to continue forwarding the multicast data. In other
words, PIM routers can act as multicast data filters. These filters can help implement traffic control and
also control the information available to downstream receivers to enhance data security.
Generally, a smaller distance from the filter to the multicast source results in a better filtering effect.
To configure a multicast data filter:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter public network PIM view
or VPN instance PIM view.
pim [ vpn-instance
vpn-instance-name ]
N/A
3. Configure a multicast group
filter.
source-policy acl-number
No multicast data filter by default.
This filter works not only on
independent multicast data but
also on multicast data
encapsulated in register messages.
