R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

178
Ste
p
Command Remarks
3. Enable the SA cache mechanism. cache-sa-enable
Optional.
Enabled by default.
4. Configure the maximum number of (S,
G) entries learned from the specified
MSDP peer that the router can cache.
peer peer-address
sa-cache-maximum sa-limit
Optional.
8192 by default.
Displaying and maintaining MSDP
Task Command Remarks
Display brief information about
MSDP peers.
display msdp [ all-instance | vpn-instance
vpn-instance-name ] brief [ state { connect |
down | listen | shutdown | up } ] [ | { begin
| exclude | include } regular-expression ]
Available in any view.
Display detailed information about
the status of MSDP peers.
display msdp [ all-instance | vpn-instance
vpn-instance-name ] peer-status
[ peer-address ] [ | { begin | exclude |
include } regular-expression ]
Available in any view.
Display information about the (S,
G) entries in the SA cache.
display msdp [ all-instance | vpn-instance
vpn-instance-name ] sa-cache [ group-address
| source-address | as-number ] * [ | { begin |
exclude | include } regular-expression ]
Available in any view.
Display the number of (S, G)
entries in the SA cache.
display msdp [ all-instance | vpn-instance
vpn-instance-name ] sa-count [ as-number ] [ |
{ begin | exclude | include }
regular-expression ]
Available in any view.
Reset the TCP connection with an
MSDP peer.
reset msdp [ all-instance | vpn-instance
vpn-instance-name ] peer [ peer-address ]
Available in user view.
Clear (S, G) entries in the SA
cache.
reset msdp [ all-instance | vpn-instance
vpn-instance-name ] sa-cache
[ group-address ]
Available in user view.
Clear statistics for MSDP peers.
reset msdp [ all-instance | vpn-instance
vpn-instance-name ] statistics [ peer-address ]
Available in user view.
MSDP configuration examples
This section provides examples of configuring MSDP.
PIM-SM Inter-domain multicast configuration
Network requirements
As shown in Figure 54, the network has two OSPF ASs: AS 100 and AS 200. BGP runs between the two
ASs.
PIM-SM 1 belongs to AS 100, and PIM-SM 2 and PIM-SM 3 belong to AS 200. Each PIM-SM domain
has at least one multicast source or receiver.
