242
GE2/1/3 10.110.2.1/24
GE2/1/2
10.110.5.2/24
Loop1 1.1.1.1/32 GE2/1/3 10.110.12.2/24
PE 2 GE2/1/1 192.168.7.1
/
24
CE b1
GE2/1/1
10.110.8.1/24
GE2/1/2 10.110.3.1/24
GE2/1/2
10.110.3.2/24
GE2/1/3 10.110.4.1/24 CE b2 GE2/1/1 10.110.11.1/24
Loop1
1.1.1.2
/
32
GE2/1/2
10.110.6.2
/
24
Configuration procedure
1. Configure PE 1:
# Configure a Router ID, enable IP multicast routing on the public network, configure an MPLS LSR
ID, and enable the LDP capability.
<PE1> system-view
[PE1] router id 1.1.1.1
[PE1] multicast routing-enable
[PE1] mpls lsr-id 1.1.1.1
[PE1] mpls
[PE1-mpls] quit
[PE1] mpls ldp
[PE1-mpls-ldp] quit
# Create VPN instance a, configure an RD for it, and create an ingress route and an egress route
for it.
[PE1] ip vpn-instance a
[PE1-vpn-instance-a] route-distinguisher 100:1
[PE1-vpn-instance-a] vpn-target 100:1 export-extcommunity
[PE1-vpn-instance-a] vpn-target 100:1 import-extcommunity
# Enable IP multicast routing in VPN instance a, configure a share-group address, associate an
MTI with the VPN instance, and define the switch-group-pool address range.
[PE1-vpn-instance-a] multicast routing-enable
[PE1-vpn-instance-a] multicast-domain share-group 239.1.1.1 binding mtunnel 0
[PE1-vpn-instance-a] multicast-domain switch-group-pool 225.2.2.0 28
[PE1-vpn-instance-a] quit
# Configure an IP address, and enable PIM-SM and LDP capability on the public network interface
GigabitEthernet 2/1/1.
[PE1] interface gigabitethernet 2/1/1
[PE1-GigabitEthernet2/1/1] ip address 192.168.6.1 24
[PE1-GigabitEthernet2/1/1] pim sm
[PE1-GigabitEthernet2/1/1] mpls
[PE1-GigabitEthernet2/1/1] mpls ldp
[PE1-GigabitEthernet2/1/1] quit
# Bind GigabitEthernet 2/1/2 with VPN instance a, configure an IP address and enable IGMP
and PIM-SM on the interface.
[PE1] interface gigabitethernet 2/1/2
[PE1-GigabitEthernet2/1/2] ip binding vpn-instance a
[PE1-GigabitEthernet2/1/2] ip address 10.110.1.1 24
[PE1-GigabitEthernet2/1/2] igmp enable
[PE1-GigabitEthernet2/1/2] pim sm
[PE1-GigabitEthernet2/1/2] quit
