252
[CEb2-GigabitEthernet2/1/2] ip address 10.110.6.2 24
[CEb2-GigabitEthernet2/1/2] pim sm
[CEb2-GigabitEthernet2/1/2] quit
# Configure RIP.
[CEb2] rip 3
[CEb2-rip-3] network 10.0.0.0
10. Verify the configuration:
# Display the local share-group information of VPN instance a on PE 1.
<PE1> display multicast-domain vpn-instance a share-group local
MD local share-group information for VPN-Instance: a
Share-group: 239.1.1.1
MTunnel address: 1.1.1.1
# Display the local share-group information of VPN instance a on PE 2.
<PE2> display multicast-domain vpn-instance a share-group local
MD local share-group information for VPN-Instance: a
Share-group: 239.1.1.1
MTunnel address: 1.1.1.2
# Display the local share-group information of VPN instance b on PE 2.
<PE2> display multicast-domain vpn-instance b share-group local
MD local share-group information for VPN-Instance: b
Share-group: 239.2.2.2
MTunnel address: 1.1.1.2
# Display the local share-group information of VPN instance a on PE 3.
<PE3> display multicast-domain vpn-instance a share-group local
MD local share-group information for VPN-Instance: a
Share-group: 239.1.1.1
MTunnel address: 1.1.1.3
# Display the local share-group information of VPN instance b on PE 3.
<PE3> display multicast-domain vpn-instance b share-group local
MD local share-group information for VPN-Instance: b
Share-group: 239.2.2.2
MTunnel address: 1.1.1.3
Multi-AS MD VPN configuration example
Network requirements
Item Network re
q
uirements
Multicast sources
and receivers
• In VPN a, S 1 is a multicast source, and R 2 is a receiver.
• In VPN b, S 2 is a multicast source, and R 1 is a receiver.
• For VPN a, the share-group address is 239.1.1.1, and the range of its
switch-group-pool addresses is 225.1.1.0 to 225.1.1.15.
• For VPN b, the share-group address is 239.4.4.4, and the range of its
switch-group-pool addresses is 225.4.4.0 to 225.4.4.15.
