Configuring static joining
After an interface is configured as a static member of an IPv6 multicast group or an IPv6 multicast source
and group, it will act as a virtual member of the IPv6 multicast group to receive IPv6 multicast data
addressed to that IPv6 multicast group for the purpose of testing IPv6 multicast data forwarding.
Configuration guidelines
• Before you can configure an interface on an IPv6 PIM-SM device as a static member of an IPv6
multicast group or an IPv6 multicast source and group:
{ If the interface is IPv6 PIM-SM enabled, it must be an IPv6 PIM-SM DR.
{ If this interface is MLD enabled but not IPv6 PIM-SM enabled, it must be an MLD querier. For
more information about IPv6 PIM-SM and a DR, see "Configuring IPv6 PIM."
• A static member port does not respond to queries from the MLD querier. When you configure an
interface as a static member port or cancel this configuration on the interface, the interface does not
unsolicitedly send any MLD report or an MLD done message.
To configure a static member of an IPv6 multicast group or an IPv6 multicast source and group:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure a static member of
an IPv6 multicast group or an
IPv6 multicast source and
group.
mld static-group
ipv6-group-address [ source
ipv6-source-address ]
By default, an interface is not a
static member of any IPv6 multicast
group or IPv6 multicast source and
group.
Configuring an IPv6 multicast group filter
To restrict the hosts on the network attached to an interface from joining certain IPv6 multicast groups,
you can set an IPv6 ACL rule on the interface so that the interface maintains only the IPv6 multicast
groups matching the criteria.
To configure an IPv6 multicast group filter:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter interface view.
interface interface-type
interface-number
N/A
3. Configure an IPv6 multicast
group filter.
mld group-policy acl6-number
[ version-number ]
By default, no IPv6 group filter is
configured on the interface. That is,
hosts on the current interface can
join any valid multicast group.
Setting the maximum number of IPv6 multicast groups that an
interface can join
