R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

21
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter IGMP-snooping view.
igmp-snooping N/A
3. Set the aging timer for the
dynamic router ports.
router-aging-time interval 105 seconds by default.
4. Set the aging timer for the
dynamic member ports.
host-aging-time interval 260 seconds by default.
Setting aging timers for the dynamic ports in a VLAN
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter VLAN view . vlan vlan-id N/A
3. Set the aging timer for the
dynamic router ports.
igmp-snooping router-aging-time
interval
105 seconds by default.
4. Set the aging timer for the
dynamic member ports.
igmp-snooping host-aging-time
interval
260 seconds by default.
Configuring static ports
If all hosts attached to a port are interested in the multicast data addressed to a particular multicast group
or the multicast data that a particular multicast source sends to a particular group, you can configure the
port as a static member port for the specified multicast group or the specified multicast source and group.
You can also configure a port to be a static router port, through which the router can forward all the
multicast traffic that it received.
Configuration guidelines
• A static member port does not respond to queries from the IGMP querier. When you configure a
port as a static member port or cancel this configuration on the port, the port does not unsolicitedly
send any IGMP report or an IGMP leave message.
• Static member ports and static router ports never age out. To remove such a port, use the
corresponding undo command.
Configuration procedure
To configure static ports:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter Layer 2 Ethernet
interface view or Layer 2
aggregate interface view, or
enter port group view.
• Enter Layer 2 Ethernet interface
view or Layer 2 aggregate
interface view:
interface interface-type
interface-number
• Enter port group view:
port-group manual
port-group-name
Use either command.
