R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

329
Ste
p
Command Remarks
4. Configure a legal C-RP
address range and the range
of IPv6 multicast groups to be
served.
crp-policy acl6-number
Optional.
No restrictions by default.
Enabling embedded RP
When the embedded RP feature is enabled, the router can resolve the RP address directly from the IPv6
multicast group address of an IPv6 multicast packets. This RP can replace the statically configured RP or
the RP dynamically calculated based on the BSR mechanism. Thus, the DR does not need to know the RP
address beforehand.
The default embedded RP address scopes are FF7x::/12 and FFFx::/12. Here "x" refers to any legal
address scope. For more information about the Scope field, see "Multicast overview."
Perform this configuration on all routers in the IPv6 PIM-SM domain.
To enable embedded RP:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter IPv6 PIM view. pim ipv6 N/A
3. Enable embedded RP.
embedded-rp [ acl6-number ]
Optional.
By default, embedded RP is
enabled for IPv6 multicast groups
in the default embedded RP
address scopes.
Configuring C-RP timers globally
To enable the BSR to distribute the RP-set information within the IPv6 PIM-SM domain, C-RPs must
periodically send C-RP-Adv messages to the BSR. The BSR learns the RP-set information from the received
messages, and encapsulates its own IPv6 address together with the RP-set information in its bootstrap
messages. The BSR then floods the bootstrap messages to all IPv6 routers in the network.
Each C-RP encapsulates a timeout value in its C-RP-Adv messages. After receiving a C-RP-Adv message,
the BSR obtains this timeout value and starts a C-RP timeout timer. If the BSR fails to obtain a subsequent
C-RP-Adv message from the C-RP when the timer times out, the BSR assumes the C-RP to have expired or
become unreachable.
You must configure the C-RP timers on C-RP routers.
To configure C-RP timers globally:
Ste
p
Command Remarks
1. Enter system view. system-view N/A
2. Enter IPv6 PIM view.
pim ipv6 N/A
3. Configure the C-RP-Adv
interval.
c-rp advertisement-interval interval
Optional.
60 seconds by default.
4. Configure C-RP timeout timer.
c-rp holdtime interval
Optional.
150 seconds by default.
