R3102-R3103-HP 6600/HSR6600 Routers IP Multicast Configuration Guide

83
Task Command Remarks
Display IGMP configuration and
operation information.
display igmp [ all-instance |
vpn-instance vpn-instance-name ]
interface [ interface-type
interface-number ] [ verbose ] [ |
{ begin | exclude | include }
regular-expression ]
Available in any view.
Display the information of IGMP
proxying groups.
display igmp [ all-instance |
vpn-instance vpn-instance-name ]
proxying group [ group-address ]
[ verbose ] [ | { begin | exclude |
include } regular-expression ]
Available in any view.
Display information in the IGMP
routing table.
display igmp [ all-instance |
vpn-instance vpn-instance-name ]
routing-table [ source-address
[ mask { mask | mask-length } ] |
group-address [ mask { mask |
mask-length } ] | flags { act | suc } ]
* [ | { begin | exclude | include }
regular-expression ]
Available in any view.
Display IGMP SSM mappings.
display igmp [ all-instance |
vpn-instance vpn-instance-name ]
ssm-mapping group-address [ |
{ begin | exclude | include }
regular-expression ]
Available in any view.
Display the multicast group
information created from IGMPv1
and IGMPv2 reports based on the
configured IGMP SSM mappings.
display igmp [ all-instance |
vpn-instance vpn-instance-name ]
ssm-mapping group
[ group-address | interface
interface-type interface-number ]
[ verbose ] [ | { begin | exclude |
include } regular-expression ]
Available in any view.
Display information about the hosts
that join the group based on IGMP
SSM mappings on an interface.
display igmp ssm-mapping host
interface interface-type
interface-number group
group-address source
source-address [ | { begin |
exclude | include }
regular-expression ]
Available in any view.
Remove all the dynamic IGMP
group entries of a specified IGMP
group or all IGMP groups.
reset igmp [ all-instance |
vpn-instance vpn-instance-name ]
group { all | interface
interface-type interface-number
{ all | group-address [ mask { mask
| mask-length } ] [ source-address
[ mask { mask | mask-length } ] ] } }
Available in user view.
This command cannot remove
static IGMP group entries.
This command might cause an
interruption of receivers' reception
of multicast data.
Remove all the dynamic Layer 2
port entries of a specified IGMP
group or all IGMP groups
(available only on the
6604/6608/6616 router).
reset igmp group port-info { all |
group-address } [ vlan vlan-id ]
Available in user view.
This command cannot remove the
static Layer 2 port entries of IGMP
groups.
