R3303-HP 6600/HSR6600 Routers OAA Command Reference

8
<Sysname> display acfp rule-cache
ACFP rule-cache total items: 2
Idx SIP Sport DIP DPort Pro InIf OutIf
----------------------------------------------------------------------
1021 202.153.124.111 62534 202.124.152.234 32456 4 GE2/2 GE1/0/1
Precedence ToS DSCP TCPFlag TCPMask Fragment Action
----------------------------------------------------------------------
7 15 Af12 010100 010100 true redirect
Idx SIP Sport DIP DPort Pro InIf OutIf
----------------------------------------------------------------------
895 202.153.124.111 62534 202.124.152.234 32456 1 GE2/2 GE1/0/1
Precedence ToS DSCP TCPFlag TCPMask Fragment Action
----------------------------------------------------------------------
3 14 Be 010100 010100 true deny
Table 3 Command output
Field Descri
p
tion
ACFP rule-cache total items Number of ACFP rule cache information entries.
Idx Hash index.
SIP Source IP address.
SPort Source port number.
DIP Destination IP address.
DPort Destination port number.
Pro
Protocol of the packet, indicated by a number in the range of 0 to 255..
Common protocol types include:
• 1—ICMP.
• 2—IGMP.
• 3—TCP.
• 4—UDP.
InIf Inbound interface of the packet.
OutIf Outbound interface of the packet.
Precedence Packet precedence, indicated by a number in the range of 0 to 7.
Tos Type of service, indicated by a number in the range of 0 to 15.
DSCP
Differentiated Services Code Point, indicated by characters for Be, Ef, Af11,
Af12, Af13, Af21, Af22, Af23, Af31, Af32, Af33, Af41, Af42, Af43, Cs1,
Cs2, Cs3, Cs4, Cs5, Cs6, and Cs7 and indicated by a number in the range of
0 to 63 for other code points.
TCPFlag
Six bits representing URG, ACK, PSH, RST, SYN, and FIN respectively from
low to high.
