234
Expires at Jul 10 2008 09:45:01 (288 seconds left)
Table 60 Command output
Field Descri
p
tion
Total number Total number of prefix bindings.
Prefix Assigned IPv6 prefix.
Type
Type of a prefix binding:
• Static(F)—Free static binding, indicating the static prefix has not been
assigned to the client.
• Static(O)—Offered static binding. If the server replies with an Advertise
message to the client during the four-step message exchange, the server sets
the type of the static binding configured for the client to Static(O).
• Static(C)—Committed static binding, indicating the static IPv6 prefix has
been assigned to the client in a Reply message.
• Auto(O)—Offered dynamic binding. If the server selects a dynamic IPv6
prefix and replies with an Advertise message to the client during the four-step
message exchange, the server sets the type of the dynamic IPv6 prefix
binding to Auto(O).
• Auto(C)—Committed dynamic binding, indicating the dynamic IPv6 prefix
has been assigned to the client in a Reply message.
Pool Address pool to which the prefix binding belongs.
Expiration time
Time when the prefix lease expires. If the lease expires after the year 2100, this
field displays after 2100. For a free static binding, this field displays Not
available.
Prefix Pool
Prefix pool to which the prefix binding belongs. For a free static binding, this
field is blank.
Client IPv6 address of the DHCPv6 client. For a free static binding, this field is blank.
DUID Client DUID.
IAID Client IAID. For a free static binding without IAID configured, this field is blank.
Preferred lifetime Preferred lifetime of the prefix, in seconds.
valid lifetime Valid lifetime of the prefix, in seconds.
Expires at
Time when the prefix expires. If the lease expires after the year 2100, this field
displays "Expires after 2100."
display ipv6 dhcp server statistics
Use display ipv6 dhcp server statistics to display packet statistics on the DHCPv6 server.
Syntax
display ipv6 dhcp server statistics [ | { begin | exclude | include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
