R3303-HP HSR6800 Routers Layer 3 - IP Services Command Reference

258
Views
Any view
Default Level
1: Monitor level
Parameters
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Fundamentals Configuration Guide.
begin: Displays the first line that matches the specified regular expression and all lines that follow.
exclude: Displays the lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Usage guidelines
The output does not include the information about port translation through the NAPT-PT mechanism.
Examples
# Display the static and dynamic NAT-PT address mappings.
<Sysname> display natpt address-mapping
Address Mappings (V6toV4):
IPv4 Address IPv6 Address Type
1.1.1.1 3001::0001 SOURCE
2.2.2.2 3001::0002 DESTINATION
V6Server static mapping:
IPv4Address IPv6 Address Pro
1.1.1.1^ 6 3001::0003^ 1270 TCP
Table 67 Command output
Field Descri
p
tion
Address Mappings (V6toV4)
Displays static and dynamic NAT-PT address mappings on the IPv6
side.
IPv4 Address IPv4 address.
IPv6 Address IPv6 address.
Type
Type of the mapping:
• SOURCE—Mapping created according to the configuration on the
IPv6 side.
• DESTINATION—Mapping created according to the configuration
on the IPv4 side.
V6Server static mapping Displays the NAT-PT mapping of an IPv6 server.
IPv4Address IPv4 address and port number.
IPv6 Address Corresponding IPv6 address and port number.
Pro Protocol type.
