21
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Usage guidelines
If you do not specify the interface type or interface number, this command displays the brief IP
configuration information for all Layer 3 interfaces.
If you specify only the interface type, this command displays the brief IP configuration information for all
Layer 3 interfaces of the specified type.
If you specify both the interface type and interface number, this command displays only the brief IP
configuration information for the specified interface.
Examples
# Display brief IP configuration information for GigabitEthernet interfaces.
<Sysname> display ip interface GigabitEthernet brief
*down: administratively down
(s): spoofing (l): loopback
Interface Physical Protocol IP Address Description
GE3/0/1 up up 192.168.20.231 --
GE3/0/5 down down -- --
Table 4 Command output
Field Descri
p
tion
*down: administratively
down
The interface is administratively shut down with the shutdown command.
(s) : spoofing
Spoofing attribute of the interface. It indicates that an interface might have no
link present even when its link layer protocol is displayed up or the link is set up
only on demand.
(l) : loopback Link loopback test supported by PPP and HDLC.
Interface Interface name.
Physical
Physical state of the interface:
• *down—The interface is administratively down; that is, the interface is shut
down with the shutdown command.
• down—The interface is administratively up but its physical state is down.
• up—Both the administrative and physical states of the interface are up.
Protocol
Link layer protocol state of the interface:
• down—The protocol state of the interface is down.
• up—The protocol state of the interface is up.
• up(s)—The protocol state of the interface is up (spoofing).
• up(l)—The protocol state of the interface is up (loopback).
• down(l)—The protocol state of the interface is down (loopback).
IP Address
IP address of the interface. If no IP address is configured, two hyphens (--) are
displayed.
Description
Interface description information. If no IP address is configured, two hyphens (--)
are displayed.
At most, 27 characters can be displayed. If there are more than 27 characters,
only the first 24 characters and three dots (…) are displayed.
