40
Table 9 Command output
Field Description
Global Pool Statistics of a DHCP address pool.
Pool Number Number of address pools.
Auto Number of dynamic bindings.
Manual Number of static bindings.
Expire Number of expired bindings.
BOOTP Request
DHCP packets received from clients:
• DHCPDISCOVER.
• DHCPREQUEST.
• DHCPDECLINE.
• DHCPRELEASE.
• DHCPINFORM.
• BOOTPREQUEST.
BOOTP Reply
DHCP packets sent to clients:
• DHCPOFFER.
• DHCPACK.
• DHCPNAK.
• BOOTPREPLY.
Bad Messages Number of bad messages.
Related commands
reset dhcp server statistics
display dhcp server tree
Use display dhcp server tree to display information for DHCP address pools.
Syntax
display dhcp server tree { all | pool [ pool-name ] } [ | { begin | exclude | include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
Parameters
all: Displays information for all DHCP address pools.
pool [ pool-name ]: Displays information for a specific address pool. The pool name argument is a string
of 1 to 35 characters. If you do not specify any pool name, this command displays information for all
address pools.
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Fundamentals Configuration Guide.
