B
Configuring the CTL700 Tape Library
for the NonStop S-Series Server
With the IOAM Enclosure
The section covers:
Configuration Overview
You can attach the tape library (control path and data path) to a NonStop S-series
server via an IOAM enclosure. The tape library attaches to the FCSA (Fibre Channel
ServerNet adapter) in the IOAM enclosure. The ServerNet switch board in the IOAM
enclosure connects to an MSEB (modular ServerNet expansion board) on a NonStop
S-series server via a fiber-optic cable.
For more information on the IOAM enclosure, see the Modular I/O Installation and
Configuration Guide.
Adding the Control Path and Data Path
To add the control path, issue this SCF command:
SCF> ADD SCSI $device, SENDTO STORAGE, PRIMARYLOCATION
(group, module, slot), PRIMARYSAC sac-id, LUN lun-id,
PRIMARYPORT 64-bit-portname
Example:
SCF> ADD SCSI $L700, SENDTO STORAGE, PRIMARYLOCATION
(110,2,2), PRIMARYSAC 2, LUN 0, PRIMARYPORT 1234567891234567
Configuration Overview B-1
Adding the Control Path and Data Path B-1
Note. The control path is used to control the robot, and the data path is used to control the
tape drive.
Note. To obtain the portname numbers for your control path and data path, contact a service
representative from STK. The portname numbers used in this section are examples only.
