Configuring the CTL700 Tape Library for the
NonStop S-Series Server With the IOAM Enclosure
L700 (CTL700) Installation and User’s Guide—527338-008
B-2
Adding the Control Path and Data Path
To add the data path:
1. In SCF, issue this command:
SCF> ADD TAPE $tape, SENDTO STORAGE, LOCATION (group, module,
slot), SAC sac-id, PORTNAME 64-bit-portname, LUN lun-id
Example:
SCF> ADD TAPE $M8503, SENDTO STORAGE, LOCATION (110,2,2), SAC
2, LUN 0, PORT 50060B00002E69CD
2. To start the tape drive on the server, issue this command in SCF:
SCF> START TAPE $tape
Example:
SCF> START TAPE $M8503
For complete details about the ADD and STATUS commands, including command
syntax, see the SCF Reference Manual for the Storage Subsystem.
Note. WWN (portname) for each port will be labeled on the back of each tape drive.
Note. The LUN (logical unit number) for all Fibre Channel tape storage devices directly
attached to the IOAM enclosure is 0.
