Installing the Tape Library
L700 (CTL700) Installation and User’s Guide—527338-008
3-3
Installing the Expansion Frame
b. Gently pry up the array lock and pull back on the bottom of the assembly
to remove it. Place the tape cartridge array lock aside.
c. Lift up and pull out the top tape cartridge array.
d. Continue removing the tape cartridge arrays until you have clear access
to the mounting holes. Place all tape cartridge arrays clear of the work
area.
4. Move the robotic hand to gain access to theta stop 3. Remove theta stop
number 3.
5. If theta stop 1 is present, remove it also. Only theta stop 2 should remain.
6. Refer to Figure 3-3 on page 3-5 while unpacking the expansion frame and its
attachment screws from the shipping package. Lay the expansion frame on
its back.
7. Measure the distance from the floor of the room to the inside floor of the tape
library.
8. Adjust the four leveling bolts on the expansion frame (measures from the
inside floor of the expansion frame to the bottom of the leveling bolt) to
approximate the distance measured in the previous step.
9. Raise the expansion frame and position it up against the opening of the tape
library frame.
10. Refer to Figure 3-4
on page 3-6. Note the two alignment pins at the top and
bottom of the frame. Move the frame close to the rear of the tape library.
Caution. Be careful not to bend the leveling bolts in the next step.
