L700 (CTL700) Installation and User's Guide (G06.28+, H06.04+, J06.03+)

Controls and Indicators on the CTL700 Tape Library
L700 (CTL700) Installation and User’s Guide—527338-008
4-10
Display Screens
This screen lets you set:
Drive Configuration
Accessible from the Main Configuration menu, the drive configuration menu lets you
modify portions of each drive’s configuration. Figure 4-10 shows an example screen.
For each drive, the menu displays the drive position, drive type, SCSI ID and indicates
whether the drive is on the same SCSI bus as the library.
The panel displays only 16 lines per screen. If the library contains more than eight
drives, use the down arrow button to scroll to drive 09 and higher. For more
information, see Entering Tape Drive Information on page 5-9.
SCSI ID Tape library’s SCSI identification number
Fast Load Fast Load feature on or off
Date Current date
Time Current time
SCSI Type Type of SCSI bus that connects the tape library to
the server
Auto Clean Whether Auto Clean is enabled
CAPs Number of CAPs installed
User Cells Number of data storage cells the library contains
Drive Column Number of tape drive columns installed
Expansion Frame Whether an expansion frame is installed
Note. The cursor position is saved on all screens that list the tape library’s tape drives.
