L700 (CTL700) Installation and User's Guide (G06.28+, H06.04+, J06.03+)

Contents
L700 (CTL700) Installation and User’s Guide—527338-008
iv
A. Configuring the CTL700 Tape Library for the
NonStop NS-Series Server
Programming and Configuration Considerations 9-17
Choosing Block Size 9-17
Using a Tape Drive for a Tape Boot or Tape Load 9-17
A. Configuring the CTL700 Tape Library for the NonStop NS-
Series Server
Fibre Channel ServerNet Adapter Connection A-1
Configuring the SCSI Control Path A-2
Configuring Fibre Channel Tape Drives A-3
Configuring the NonStop NS-Series Server to the CTL7FC Fibre Channel Interface
Card A-9
Adding the Control Path A-11
B. Configuring the CTL700 Tape Library for the NonStop
S-Series Server With the IOAM Enclosure
Configuration Overview B-1
Adding the Control Path and Data Path B-1
C. Configuring the CTL700 Tape Library for the NonStop
BladeSystem Server
Configuration Overview C-1
Adding the Control Path and Data Path C-1
Start the Tape Library and Tape Drive C-2
Verify the Tape Configuration C-2
Troubleshoot the Tape Configuration C-3
Safety and Compliance
Index
Examples
Figures
Figure 1-1. The CTL700 Tape Library 1-1
Figure 2-1.
Space Needed for CTL700 Tape Library 2-2
Figure 2-2.
Power and Signal Cable Routing 2-3
Figure 2-3. Unpacking the Tape Library 2-5
Figure 2-4. Column Shipping Pin 2-7
Figure 2-5. Theta Shipping Pin 2-8
Figure 2-6. Z Column Movement 2-9
Figure 2-7.
Moving the Z Carriage Assembly 2-10
