L700 (CTL700) Installation and User’s Guide—527338-008
7-1
7 Tape Drives in the CTL700 Tape
Library
This section covers:
Supported Tape Drives
These tape drives are supported for a connection to a CTL700 tape library:
•
N1530A tape drive
•
CT9841FC-1 tape drive
•
M8503 tape drive
•
M8608A tape drive
The supported tape drives and their respective power supplies are field-replaceable
units (FRU). Contact your service provider if the tape drives require servicing.
The CTL700 tape library can accommodate up to twelve CT9841FC-1 tape drives, up
to twenty N1530A tape drives, up to twenty M8503 tape drives, and up to twenty
M8608A tape drives. A combination of all these tape drives can be configured.
Data Compression
The supported tape drives can write compressed or uncompressed information to a
labeled or unlabeled tape cartridge. Compression increases the cartridge capacity
(over the uncompressed format) by two to three times.
Writing compressed data on a tape cartridge means the tape drive compresses data
whenever possible. The specific amount of data stored on the tape cartridge is not
predictable because the amount of compression varies with the type of data being
written. For this reason, the amount of compressed data stored on tape cartridges can
vary significantly.
Supported Tape Drives 7-1
