L700 (CTL700) Installation and User’s Guide—527338-008
8-1
8
Configuring the CTL700 Tape Library
for the NonStop S-Series Server
The section covers:
Supported Connections
You can attach the CTL700 tape library’s control path and data path (N1530A
tape drive) to a NonStop S-series server using one of the following:
•
ServerNet/DA
•
IOMF 2 CRU
•
PMF CRU
Supported Connections 8-1
Adding the Control Path and the Data Path 8-2
Note. The control path is used to control the robot and the data path (N1530A) is used to
control the tape drive(s).
