Monitoring the G4SAs
Monitoring the G4SAs
Use the Subsystem Control Facility (SCF) or the OSM Service Connection to monitor
the G4SAs.
To monitor the G4SAs using OSM, refer to Using OSM to Monitor the System on
page 3-7.
To monitor the G4SA and its attached devices with SCF, use the SCF INFO and SCF
STATUS commands.
For example, to monitor G4SAs using SCF:
> SCF STATUS ADAPTER $ZZLAN.G1123
The LAN Configuration and Management Manual provides reference details and
examples for using the SCF INFO and SCF STATUS commands.
When monitoring G4SAs using the OSM Service Connection, the states of the G4SAs
should indicate normal operation. Table 8-2 lists the possible states for the G4SA.
Table 8-2. Service, Device, and Enabled States for the G4SA (page 1 of 2)
State Description
Service State: OK The resource is functioning normally and does not require attention or
service.
Service State:
Attention
Required
The resource requires operator attention. This condition sometimes
generates an alarm, and the component that requires attention is
colored yellow in the tree pane and in the Physical and ServerNet
views of the view pane.
Service State:
Service Required
The resource requires service. This condition generates an alarm, and
the component that requires service is colored red in the tree pane and
in the Physical and ServerNet views of the view pane
Device State:
Aborting
Processing is terminating.
Device State:
Defined
State is defined by the NonStop OS.
Device State:
Degraded
Performance is degraded.
Device State:
Diagnose
A diagnostic test is running on the component.
Device State:
Initializing
Processing is starting up.
Device State: Not
Configured
The component is not configured.
Device State:
Started
The component is running.
