Processors and Components: Monitoring and
Recovery
HP Integrity NonStop NS-Series Operations Guide—529869-001
9-19
Backing Up a Processor Dump to Tape
Troubleshooting and Recovery Operations for Disk Dumps
If a message indicates that the dump was not successful, repeat Dumping a Processor
to Disk on page 9-13 using the other ServerNet fabric.
If a halt code for the selected processor appears in the Processor Status dialog box of
the OSM Low-Level Link, look it up in the Processor Halt Codes Manual for further
information about the cause of failure and the appropriate recovery procedure.
Backing Up a Processor Dump to Tape
Back up a processor dump to tape from the compressed disk file generated by the
TACL RECEIVEDUMP command (or the RCVDUMP utility):
1. Follow the instructions in Dumping a Processor to Disk on page 9-15.
2. Use the BACKUP utility to copy the processor dump to tape, as described in
Section 10, Disk Drives: Monitoring and Recovery.
3. See Submitting Information to Your Service Provider on page 9-19.
Replacing Processor Memory
Processor memory is field-replaceable for all Integrity NonStop systems. Call your
service provider. If memory units cannot be replaced, the memory board must be
replaced.
If the Service State attribute of a Slice object is not OK (see Monitoring Processor
Performance Using ViewSys on page 9-7), the memory board might need to be
replaced. Contact your service provider. For information, refer to the CSSI Web.
Replacing the Processor Board and Processor Entity
Processor boards and entities are field-replaceable for all Integrity NonStop systems.
Call your service provider.
Submitting Information to Your Service Provider
To help with the analysis of a processor dump, submit a backup tape of other system
configuration and operations files and some additional information.
•
Submitting Tapes of Processor Dumps on page 9-20
•
Submitting Tapes of Configuration and Operations Files on page 9-20
•
Additional Information Required by Your Service Provider on page 9-21
