Determining Your System Configuration
HP Integrity NonStop NS-Series Operations Guide—529869-001
2-7
Using SCF to Display Subsystem Configuration
Information
SCF LISTDEV: Listing the Devices on Your System
To obtain listings for most devices and processes that have a device type known to
SCF, at a TACL prompt type:
> SCF LISTDEV
In the example shown in Example 2-1, the SCF LISTDEV command lists all the
physical and logical devices on the system.
Example 2-1. SCF LISTDEV Command Output
$SYSTEM STARTUP 1> SCF LISTDEV
LDev Name PPID BPID Type RSize Pri Program
0 $0 0,3 1,3 ( 1,0 ) 102 201 \DRP14.$SYSTEM.SYS00.OPCOLL
1 $NCP 2,6 0,0 (62,0 ) 3 199 \DRP14.$SYSTEM.SYS00.NCPOBJ
3 $YMIOP 0,5 1,5 ( 6,4 ) 80 205 \DRP14.$SYSTEM.SYS00.TMIOP
5 $Z0 0,7 1,7 ( 1,2 ) 102 200 \DRP14.$SYSTEM.SYS00.OCDIST
6 $SYSTEM 0,257 1,257 ( 3,45) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
7 $ZOPR 0,8 1,8 ( 1,0 ) 102 201 \DRP14.$SYSTEM.SYS00.OAUX
63 $ZZKRN 0,294 1,328 (66,0 ) 4096 180 \DRP14.$SYSTEM.SYS00.OZKRN
64 $ZZWAN 0,291 1,298 (50,3 ) 132 180 \DRP14.$SYSTEM.SYS00.WANMGR
65 $ZZSTO 0,292 1,329 (65,0 ) 4096 180 \DRP14.$SYSTEM.SYS00.TZSTO
66 $ZZSMN 1,289 2,282 (64,1 ) 132 199 \DRP14.$SYSTEM.SYS00.SANMAN
67 $ZZSCL 1,290 2,277 (64,0 ) 132 199 \DRP14.$SYSTEM.SYS00.SNETMON
68 $ZZLAN 0,293 1,297 (43,0 ) 132 199 \DRP14.$SYSTEM.SYS00.LANMAN
86 $ZSNET 0,294 1,328 (66,0 ) 4096 180 \DRP14.$SYSTEM.SYS00.OZKRN
87 $ZSLM2 0,288 1,293 (67,0 ) 1024 221 \DRP14.$SYSTEM.SYS00.TZSLM2
91 $ZNET 0,14 1,13 (50,63) 3900 175 \DRP14.$SYSTEM.SYS00.SCP
104 $ZM03 3,279 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
105 $ZM02 2,280 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
106 $ZM01 1,280 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
107 $ZM00 0,290 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
108 $ZLOG 0,307 1,345 ( 1,0 ) 4024 150 \DRP14.$SYSTEM.SYS00.EMSACOLL
104 $ZM03 3,279 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
105 $ZM02 2,280 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
106 $ZM01 1,280 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
107 $ZM00 0,290 0,0 (45,0 ) 132 201 \DRP14.$SYSTEM.SYS00.QIOMON
108 $ZLOG 0,307 1,345 ( 1,0 ) 4024 150 \DRP14.$SYSTEM.SYS00.EMSACOLL
121 $ZIM03 3,280 0,0 (64,2 ) 132 199 \DRP14.$SYSTEM.SYS00.MSGMON
122 $ZIM02 2,285 0,0 (64,2 ) 132 199 \DRP14.$SYSTEM.SYS00.MSGMON
123 $ZIM01 1,291 0,0 (64,2 ) 132 199 \DRP14.$SYSTEM.SYS00.MSGMON
124 $ZIM00 0,305 0,0 (64,2 ) 132 199 \DRP14.$SYSTEM.SYS00.MSGMON
126 $ZEXP 0,13 1,18 (63,30) 132 150 \DRP14.$SYSTEM.SYS00.OZEXP
128 $SC26 2,281 3,285 (63,4 ) 1 199 \DRP14.$SYSTEM.SYS00.LHOBJ
129 $SC25 2,283 3,286 (63,4 ) 1 199 \DRP14.$SYSTEM.SYS00.LHOBJ
131 $DATA6 0,296 1,287 ( 3,42) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
132 $DATA5 0,297 1,286 ( 3,42) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
133 $DATA4 0,298 1,285 ( 3,44) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
134 $DATA3 0,299 1,284 ( 3,42) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
135 $DATA2 0,300 1,283 ( 3,42) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
136 $DATA1 0,301 1,282 ( 3,44) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
137 $DATA 0,302 1,281 ( 3,44) 4096 220 \DRP14.$SYSTEM.SYS00.TSYSDP2
145 $ZOLHD 0,369 1,359 ( 1,30) 132 150 \DRP14.$SYSTEM.SYS00.EMSDIST
167 $ZTC0 0,338 1,332 (48,0 ) 32000 200 \DRP14.$SYSTEM.SYS00.TCPIP
168 $ZTNT 0,340 1,334 (46,0 ) 6144 149 \DRP14.$SYSTEM.SYS00.TELSERV
200 $ZPMON 0,375 0,0 (24,0 ) 4096 180 \DRP14.$SYSTEM.SYS00.OSSMON
