Determining Your System Configuration
HP Integrity NonStop NS-Series Operations Guide—529869-001
2-14
Additional Subsystems Controlled by SCF
CP6100 Communications Process Subsystem 51 0
Envoy Byte-synchronous and asynchronous
communications data link-level interface
70
EnvoyACP/XF Byte-synchronous communications data
link-level interface
11 40, 41, 42,
43
Expand Expand network control process ($NCP) or
line-handler process
62 or 63 2, 3, 5, or 6
GDS General Device Support 57
OSIAPLMG Open Systems Interconnection/Application
Manager
55 20
OSIAS Open Systems Interconnection/Application
Services
55 1-5
OSICMIP Open Systems Interconnection/Common
Management Information Protocol
55 24
OSIFTAM Open Systems Interconnection/File
Transfer, Access, and Management
55 21 or 25
OSIMHS Open Systems Interconnection/Message
Handling System
55 11 or 12
OSITS Open Systems Interconnection/Transport
Services
55 55, 4
OSS Open System Services 24 0
PAM Port Access Method
QIO Queued I/O product 45 0
SCP Subsystem Control Point 50 63
SCS SQL Communications Subsystem 38 0
SNAX/APN SNAX Advanced Peer Networking 58 or 13 0
SNAX/XF SNAX Extended Facility 58 or 13
SNAXAPC SNAX Advanced Program Communication 13 10
SNAXCRE SNAX Creator-2 18 0
SNAXHLS SNAX High-Level Support 13 5
SNMP Simple Network Management Protocol
agent
31 0
TELSERV TCP/IP TELNET product 46 0
TR3271 TR3271 Access Method 60 1 or 11
X25AM X.25 Access Method 61 0
Table 2-7. Subsystem Objects Controlled by SCF (page 2 of 2)
Subsystem
Acronym Description
Device
Type
Device
Subtype
