Processes: Monitoring and Recovery
HP Integrity NonStop NS-Series Operations Guide—529869-001
5-4
Monitoring IOPs
Monitoring IOPs
For a list of manuals that provide more information about monitoring I/O processes
(IOPs), refer to the WAN Subsystem Configuration and Management Manual, the
SWAN Concentrator and WAN Subsystem Troubleshooting Guide, and the Expand
Configuration and Management Manual.
Monitoring Generic Processes
Because generic processes are configured using the SCF interface to the Kernel
subsystem, you specify the $ZZKRN Kernel subsystem manager process when
monitoring a generic process. These SCF commands are available for monitoring
$ZZKRN and other generic processes:
Monitoring the Status of $ZZKRN
To monitor the status of the $ZZKRN Kernel subsystem manager process, at a TACL
prompt:
> SCF STATUS SUBSYS $ZZKRN
This example shows the output produced by this command:
Monitoring the Status of All Generic Processes
To monitor the status of all generic processes controlled by $ZZKRN, at a TACL
prompt:
> SCF STATUS PROCESS $ZZKRN.#*
$ZLM01 1,342 200 P 015 255,255 $SYSTEM.SYS14.LANMON $ZHOME
$ZTC0 B 1,352 200 P 011 255,255 $SYSTEM.SYS14.TCPIP $ZHOME
$ZTNT B 1,355 149 001 255,255 $SYSTEM.SYS14.TELSERV $ZHOME
$ZPORT B 1,357 149 001 255,255 $SYSTEM.SYS14.LISTNER $ZHOME
$KLA9E 1,424 147 001 255,255 $DATA2.KMZTT.LOGGER $ZTNT.#PTBY5D
$ZTM02 2,5 200 P 017 255,255 $SYSTEM.SYS14.TMFMON2 $YMIOP.#CLCI
$GRD2 2,243 147 P 001 255,255 $DATA2.QA9050.RUNNER $ZTNT.#PTBY5CV
$ZP02A B 2,300 195 001 255,255 $SYSTEM.ZRPC.PORTMAP $ZHOME
$ZCMOM B 2,303 150 001 255,255 $SYSTEM.SYS14.CIMOM $ZHOME
INFO Displays configuration information for the specified objects
NAMES Displays a list of subordinate object types and names for the
specified objects
STATUS Displays current status information about the specified objects
1 -> STATUS SUBSYS $ZZKRN
NONSTOP KERNEL - Status SUBSYS \COMM.$ZZKRN
Name State Processes
(conf/strd)
\COMM.$ZZKRN STARTED ( 25/22 )
