Monitoring the WAN Subsystem
This example shows a listing of the status of all PIFs on $ZZLAN.G11123:
> SCF STATUS PIF $ZZLAN.G11123.*
4. The LIF provides an interface to the PIF. The LIF object corresponds to logical
processes that handle data transferred between the LAN and a system using the
ServerNet architecture. To monitor the status of a LIF:
> SCF STATUS LIF lif-name
A listing similar to this example is sent to your home terminal:
This example shows a detailed listing of the status of the LIF on $ZZLAN.L11021A:
> SCF STATUS LIF $ZZLAN.L11021A , DETAIL
Monitoring the WAN Subsystem
This subsection describes how to obtain the status of SWAN concentrators, data
communications devices, processes, and CLIPs. For more information on the WAN
subsystem, see the WAN Subsystem Configuration and Management Manual.
Monitoring Status for a SWAN Concentrator
To display the current status for a SWAN concentrator:
> SCF STATUS ADAPTER $ZZWAN.#concentrator-name
->STATUS PIF $ZZLAN.G11123.*
SLSA Status PIF
Name State Trace Status
$ZZLAN.G11123.0.A STARTED ON
$ZZLAN.G11123.0.B STARTED ON
$ZZLAN.G11123.0.C STOPPED OFF
$ZZLAN.G11123.0.D STARTED ON
->STATUS LIF $ZZLAN.L11021A
SLSA Status LIF
Name State Access State
$ZZLAN.L11021A STARTED UP
->STATUS LIF $ZZLAN.L11021A , DETAIL
SLSA Detailed Status LIF \SYS.$ZZLAN.L11021A
Access State............. UP
CPUs with Data Path...... ( 0, 1, 2 )
Potential Access CPUs.... ( 0, 1, 2, 3 )
State.................... STARTED
Trace Filename...........
Trace Status.............
