LSUs to Processor Switches and Processor IDs
The four cabling diagrams on the next pages illustrate the default configuration and
connections for a triplex system processor. These diagrams are not for use in installing
or cabling the system. For instructions on connecting the cables, see the NonStop NS-
Series Hardware Installation Manual.
This figure shows example connections to the default configuration of the NonStop
Blade Element reintegration links (NonStop Blade Element connectors S, T, Q, R) and
11 1 4
25
36
47
12 1 8
29
310
411
13 1 12
213
314
415
Note. Individual NonStop Blade Element enclosures might or might not reside in the same
cabinet, depending on the physical configuration of the system. But regardless of which
cabinet houses the NonStop Blade Element, LSU, and p-switch enclosures, the default cable
interconnections between them will be the same as the examples shown in the next four
cabling diagrams.
P-Switch PIC Slot PIC Port Processor Number (page 2 of 2)
