System Configuration Guidelines
HP Integrity NonStop NS-Series Planning Guide—529567-005
6-33
Default Naming Conventions
can name their resources at will and use the appropriate management applications and
tools to find out where the resource is.
However, default naming conventions for certain resources simplify creation of the
initial configuration files and automatic generation of the names of the modular
resources. When autoconfigure mode is set to ON for storage subsystems, the
preconfigured default naming convention is used to generate the names of the Fibre
Channel disk drives. Preconfigured default resource names are:
On new NonStop systems, only one of each of these processes and names is
configured:
•
TCP6SAM - $ZTC0
•
Telserv - $ZTCN0
•
Listener - $LNS0
No TFTP or WANBOOT process is configured for new NonStop systems.
Type of Object Naming Convention Example Description
Fiber Channel
disk drive
$FC number $FC10 Tenth Fibre Channel disk
drive in the system
ESS disk drive $ESS number $ESS20 Twentieth ESS disk drive in
the system
Modular tape
drive
$TAPE number $TAPE01 First modular tape drive in
the system
G4SA G group module slot G11123 G4SA in location 111.2.3
G4SA LIF L group module slot port L11123B LIF for PIF at location
111.2.3.0.B
TCP/IP process $ZTC number $ZTC0 First TCP6SAM or TCP/IP
process for the system
Telserv process $ZTN number $ZTN0 First Telserv process for the
system
Listener
process
$LSN number LSN0 First Listener process for
the system
TFTP process Automatically created by
WANMGR
None None
WANBOOT
process
Automatically created by
WANMGR
None None
SWAN
Concentrator
S number S10 Tenth SWAN concentrator
in the system
Note. Naming conventions or configurations for the dedicated service LAN TCP/IP are the
same as the TCP/IP conventions used with G-series RVUs and are named $ZTCP0 and
$ZTCP1.
