Example Configurations
HP Integrity NonStop NS-Series Planning Guide—529567-005
7-10
Example Internal Cabling
Example Internal Cabling
Topics included are:
This cabling chart for an example Integrity NonStop NS-series system, with a duplex
processor, lists the relative U location where the cable connects to its source and
destination connectors, the cable part numbers, and the label for each connection.
Connections and U locations vary according to actual system configuration. An
illustration showing the example system and the U locations of each enclosure follows
this multi-page table.
Topic Page
Example Internal Cabling
7-10
Example 4-Processor Duplex System Cabling 7-14
Example 16-Processor Triplex System Cabling 7-15
Example Cabling in System Ready for Shipment 7-17
U# Source Label Cable Destination Label U#
40 TSI #T1200 Serial N1-R1-U40-SER
TSI #T1200 SCSI:1 N1-R1-U40-SCSI-1 529789-001 LTO Tape Drive: Port 2
TSI #T1200 SCSI:0 N1-R1-U40-SCSI-0 529789-001 LTO Tape Drive: Port 1
TSI #T1200 Fibre Ch Port N1-R1-U40-FC 522745-002 IOAME1: FCSA 3.2: 1 N1-R1-U23-3-2-1 29
39 Primary FCDM1: FC-AL A1 No connection
Primary FCDM1: FC-AL B1 N1-R1-U37-B-1 522745-002 IOAME1: FCSA 2.1: 1 N1-R1-U23-2-1-1 29
37 Primary FCDM1: FC-AL A2 N1-R1-U37-A-2 522745-002 IOAME1: FCSA 3.1: 1 N1-R1-U23-3-1-1 29
Primary FCDM1: FC-AL B2 No connection
36 Mirror FCDM1: FC-AL A1 N1-R1-U34-A-1
Mirror FCDM1: FC-AL B1 N1-R1-U34-B-1 522745-002 IOAME1: FCSA 2.1: 2 N1-R1-U23-2-1-2 29
34 Mirror FCDM1: FC-AL A2 N1-R1-U34-A-2 522745-002 IOAME1: FCSA 3.1: 2 N1-R1-U23-3-1-2 29
Mirror FCDM1: FC-AL B2 N1-R1-U34-B-2
33 IOAM1: 2.14: 10/100 ENET N1-R1-U23-2.14-E U23148-A00 Maint Switch: Ethernet 4 N1-R1-U1-4 1
IOAME1: 2.14: 1 N1-R1-U23-2.14-1 522745-002 P-Switch X: Slot 4: 1 N1-R1-U17-4-1 17
IOAME1: 2.14: 2 N1-R1-U23-2.14-2 522745-002 P-Switch X: Slot 4: 2 N1-R1-U17-4-2 18
IOAME1: 2.14: 3 N1-R1-U23-2.14-3 522745-002 P-Switch X: Slot 4: 3 N1-R1-U17-4-3
IOAME1: 2.14: 4 N1-R1-U23-2.14-4 522745-002 P-Switch X: Slot 4: 4 N1-R1-U17-4-4 19
32 IOAME1: 3.14: 10/100
ENET
N1-R1-U23-3.14-E U23148-A00 Maint Switch: Ethernet 3 N1-R1-U1-3 1
IOAME1: 3.14: 1 N1-R1-U23-3.14-1 522745-002 P-Switch Y: Slot 4: 1 N1-R1-U20-4-1 20
IOAME1: 3.14: 2 N1-R1-U23-3.14-2 522745-002 P-Switch Y: Slot 4: 2 N1-R1-U20-4-2 21
IOAME1: 3.14: 3 N1-R1-U23-3.14-3 522745-002 P-Switch Y: Slot 4: 3 N1-R1-U20-4-3
IOAME1: 3.14: 4 N1-R1-U23-3.14-3 522745-002 P-Switch Y: Slot 4 N1-R1-U20-4-4 22
