Example Configurations
HP Integrity NonStop NS-Series Planning Guide—529567-005
7-11
Example Internal Cabling
29 IOAME1: FCSA 3.2: 1 N1-R1-U23-3-2-1 522745-002 M8201 (TSI T1200) Fibre
Ch Port
N1-R1-U40-FC 40
IOAME1: FCSA 3.2: 2
IOAME1: FCSA 3.1: 1 N1-R1-U23-3-1-1 522745-002 Primary FCDM1: FC-AL
A2
N1-R1-U37-A-2 37
IOAME1: FCSA 3.1: 2 N1-R1-U23-3-1-2 522745-002 Mirror FCDM1: FC-AL A2 N1-R1-U34-A-2 34
IOAME1: FCSA 2.1: 1 N1-R1-U23-2-1-1 522745-002 Primary FCDM1: FC-AL
B1
N1-R1-U37-B-1 39
IOAME1: FCSA 2.1: 2 N1-R1-U23-2-1-2 522745-002 Mirror FCDM1: FC-AL B1 N1-R1-U34-B-1 36
27 IOAME1: G4SA 2.5: A N1-R1-U23-2-5-A
IOAME1: G4SA 2.5: B N1-R1-U23-2-5-B
IOAME1: G4SA 2.5: C N1-R1-U23-2-5-C
IOAME1: G4SA 2.5: D N1-R1-U23-2-5-D
22 P-Switch Y: Slot 1: ENET 3 N1-R1-U20-1-3 U23148-A00 Maint Switch: Ethernet 2 N1-R1-U1-2 1
P-Switch Y: Slot 10: 4 N1-R1-U20-10-4 522745-002 LSUE 0: Slot 23: SNet Y N1-R1-U13--23-Y 16
P-Switch Y: Slot 4: 4 N1-R1-U20-4-4 522745-002 IOAME1: 3.14: 4 N1-R1-U23-3.14-4 32
21 P-Switch Y: Slot 10: 3 N1-R1-U20-10-3 522745-002 LSUE 0: Slot 22: SNet Y N1-R1-U13-22-Y 16
P-Switch Y: Slot 4: 3 N1-R1-U20-4-3 522745-002 OAME1: 3.14: 3 N1-R1-U23-3.14-3 32
P-Switch Y: Slot 10: 2 N1-R1-U20-10-2 522745-002 LSUE0: Slot 21: SNet Y N1-R1-U13-21-Y 16
P-Switch Y: Slot 4: 2 N1-R1-U20-4-2 522745-002 IOAME1: 3.14: 2 N1-R1-U23-3.14-2 32
P-Switch Y: Slot 3: 2 N1-R1-U20-3-2 522745-002 P-Switch X: Slot 3: 1 N1-R1-U17-3-1 17
20 P-Switch Y: Slot 10: 1 N1-R1-U20-10-1 522745-002 LSUE 0: Slot 20: SNet Y N1-R1-U13-20-Y 16
P-Switch Y: Slot 4: 1 N1-R1-U20-4-1 522745-002 IOAME1: 3.14: 1 N1-R1-U23-3.4-1-
1
32
P-Switch Y: Slot 3: 1 N1-R1-U20-3-1 522745-002 P-Switch X: Slot 3: 2 N1-R1-U17-3-2 18
19 P-Switch X: Slot 1: ENET 3 N1-R1-U17-1-3 U23148-A00 Maint Switch: Ethernet 1 N1-R1-U1-1 1
P-Switch X: Slot 10: 4 N1-R1-U17-10-4 522745-002 LSUE 0: Slot 23: SNet X N1-R1-U13--23-X 16
P-Switch X: Slot 4: 4 N1-R1-U17-4-4 522745-002 IOAME1: 2.14: 4 N1-R1-U23-2.14-4 33
18 P-Switch X: Slot 10: 3 N1-R1-U17-10-3 522745-002 LSUE 0: Slot 22: SNet X N1-R1-U13-22-X 16
P-Switch X: Slot 4: 3 N1-R1-U17-4-3 522745-002 IOAME1: 2.14: 3 N1-R1-U23-2.14-3 33
P-Switch X: Slot 10: 2 N1-R1-U17-10-2 522745-002 LSUE0: Slot 21: SNet X N1-R1-U13-21-X 16
P-Switch X: Slot 4: 2 N1-R1-U17-4-2 522745-002 IOAME1: 2.14: 2 N1-R1-U23-2.14-2 33
P-Switch X: Slot 3: 2 N1-R1-U17-3-2 522745-002 P-Switch Y: Slot 3: 1 N1-R1-U20-3-1 20
17 P-Switch X: Slot 10: 1 N1-R1-U17-10-1 522745-002 LSUE 0: Slot 20: SNet X N1-R1-U13-20-X 16
P-Switch X: Slot 4: 1 N1-R1-U17-4-1 522745-002 IOAME1: 2.14: 1 N1-R1-U23-2.4-1 33
P-Switch X: Slot 3: 1 N1-R1-U17-3-1 522745-002 P-Switch Y: Slot 3: 2 N1-R1-U20-3-2 21
16 LSUE 0: Slot 20: SNet Y N1-R1-U13-20-Y 522745-002 P-Switch Y: Slot 10: 1 N1-R1-U20-10-1 20
LSUE 0: Slot 20: SNet X N1-R1-U13-20-X 522745-002 P-Switch X: Slot 10: 1 N1-R1-U17-10-1 17
LSUE 0: Slot 21: SNet Y N1-R1-U13-21-Y 522745-002 P-Switch Y: Slot 10: 2 N1-R1-U20-10-2 21
LSUE 0: Slot 21: SNet X N1-R1-U13-21-X 522745-002 P-Switch X: Slot 10: 2 N1-R1-U17-10-2 18
LSUE 0: Slot 22: SNet Y N1-R1-U13-22-Y 522745-002 P-Switch Y: Slot 10: 3 N1-R1-U20-10-3 21
LSUE 0: Slot 22: SNet X N1-R1-U13-22-X 522745-002 P-Switch X: Slot 10: 3 N1-R1-U17-10-3 18
LSUE 0: Slot 23: SNet Y N1-R1-U13-23-Y 522745-002 P-Switch Y: Slot 10: 4 N1-R1-U20-10-4 22
LSUE 0: Slot 23: SNet X N1-R1-U13-23-X 522745-002 P-Switch X: Slot 10: 4 N1-R1-U17-10-4 19
U# Source Label Cable Destination Label U#
