HP Integrity NonStop NS-Series Planning Guide—529567-005
A-1
A Cables
Internal Cables
Available internal cables and their lengths are:
Cable Type Connectors
Length
(meters)
Length
(feet) Product ID Part Number
MMF LC-LC 2 7 M8900-02 522745
5 16 M8900-05 526016
15 49 M8900-15 526017
40 131 M8900-40 525518
80 262 M8900-80 525519
100 328 M8900100 525520
125
1
410
1
M8900125 526127
200
1
656
1
M8900200 525522
250
1
820
1
M8900250 525521
MMF LC-SC 10 33 M8910-10 526941
20 66 M8910-20 526156
50 164 M8910-50 526994
100 328 TBD 528885
125
1
410
1
M8910125 527817
MMF MTP-MTP 3 10 M8920-3
5 16 M8920-5
10 33 M8920-10
30 98 M8920-30
50 164 M8920-50
CAT-5
Ethernet
RJ-45 0.9 3 none U39929
3 10 none U23148
7.6 25 none U23150
Serial
2
RJ11 - RJ45 1.6 5 540221
1
This cable cannot be used in certain configurations. For affected configurations
and maximum cable lengths, see Cable Length Restrictions on page 6-6.
2
Power-on cable between p-switches and IOMF 2 CRUs.
