Control, Configuration, and Maintenance Tools
HP Integrity NonStop NS-Series Planning Guide—529567-005
B-9
Dedicated Service LAN
Dedicated Service LAN
A dedicated service LAN provides connectivity between the OSM console running in a
PC and the maintenance firmware in the system hardware. This dedicated service LAN
uses a ProCurve 2524 Ethernet switch for connectivity between the p-switches and
ServerNet switch boards for each IAOM) and the system console.
This subsection includes:
Integrity NonStop NS-series systems require a dedicated LAN for system maintenance
through OSM. Only components specified by HP can be connected to a dedicated
LAN. No other access to the LAN is permitted. The dedicated service LAN provides
connectivity between the OSM console running on a PC and the maintenance firmware
in the system hardware.
A basic dedicated service LAN that does not provide a fault-tolerant configuration
requires connection of these components to the ProCurve 2524 maintenance switch
installed in the modular cabinet:
•
System console for running OSM
•
Processor switch on the X fabric for OSM Low-Level Link to a down system
•
Processor switch on the Y fabric for OSM Low-Level Link to a down system
•
IOAM module 2 ServerNet board for OSM control of the I/O hardware
•
IOAM module 3 ServerNet board for OSM control of the I/O hardware
•
UPS (optional) for power-fail monitoring
•
T1200 Fibre Channel to SCSI converter (optional) for Fibre Channel tape
Topic Page
IP Addresses
B-11
Ethernet Cables B-14
SWAN Concentrator Restriction B-14
System-Up Dedicated Service LAN B-15
Dedicated Service LAN Links With One IOAM Enclosure B-16
Dedicated Service LAN Links to Two IOAM Enclosures B-17
Dedicated Service LAN Links With IOAM Enclosure and NonStop S-Series
I/O Enclosure
B-18
Dedicated Service LAN Links With NonStop S-Series I/O Enclosure B-19
Initial Configuration for a Dedicated Service LAN B-19
Operating Configurations for Dedicated Service LANs B-20
Note. System consoles require a dedicated LAN for installation and use of the complete set of
OSM client applications.
