Control, Configuration, and Maintenance Tools
HP Integrity NonStop NS-Series Planning Guide—529567-005
B-12
IP Addresses
•
T1200 FC to SCSI converter (optional)
These components have default IP addresses that are preconfigured at the factory:
Component (page 1 of 2) Location GMS
Default IP
Address Used By
ServerNet switch boards —
P-switch
N/A 100.2.14 192.231.36.202 OSM Low Level
Link
100.3.14 192.231.36.203
ServerNet switch boards —
IOAM Enclosure
N/A 110.2.14 192.231.36.222 OSM Low Level
Link
110.3.14 192.231.36.223
111.2.14 192.231.36.224
111.3.14 192.231.36.225
112.2.14 192.231.36.226
112.3.14 192.231.36.227
113.2.14 192.231.36.228
113.3.14 192.231.36.229
114.2.14 192.231.36.230
114.3.14 192.231.36.231
115.2.14 192.231.36.232
115.3.14 192.231.36.233
G4SA and NonStop
S-series E4SA, FESA,
GESA
N/A Where
installed
Device
dependent
OSM Low Level
Link, Notification
Director
Maintenance switch
(ProCurve 2524)
Rack 01 N/A 192.231.36.21 OSM Low Level
Link
Rack 02 N/A 192.231.36.22
Primary system console or
any additional system
consoles that are not
rackmounted
N/A N/A 192.231.36.1 OSM Low Level
Link, Service
Connection,
Notification
Director
Backup or rackmounted
system console
N/A N/A 192.231.36.4 OSM Low Level
Link, Service
Connection,
Notification
Director
