E
IOAM switch boards 5-16
p-switch 5-13
divergence recovery 4-8
documentation
factory-installed hardware 4-24
NonStop NS-Series C-1
packet 4-23
ServerNet adapter configuration 4-25
software migration 4-21
dual modular redundant (DMR, duplex)
processor 4-3, 4-5
dust and microscopic particles 2-5
dynamic IP addresses B-13
E
electrical disturbances 2-2
electrical power loading 3-4
elements, processor 4-2, 4-4
emergency power off (EPO) switches
HP 5500 XP UPS 2-2
Integrity NonStop NS-series
servers 2-1
NonStop S-series I/O enclosure 2-2
enclosure
combinations 1-2
dimensions 3-8
height in U 3-7
minimum, typical, maximum
number 7-1
power loading 3-4
types 1-1
weight 3-9
enclosure height in U 3-7
enclosure location 6-2
enterprise storage system (ESS) 5-23
environmental monitoring unit 5-20
European Union, harmonized cables 2-3
example
IOAM and disk drive enclosure 6-23
example hardware configurations 7-2
duplex 16-processor, three
cabinets 7-4
duplex 16-processor, two cabinets 7-5
duplex 8-processor 7-3
internal cabling 7-10
shipment cabling 7-17
triplex 16-processor 7-7
triplex 8-processor 7-6
UPS and ERM 7-8
with NonStop S-series I/O
enclosure 7-9
example system
configurations 3-11
duplex 1-2, 3-12
extended runtime module (ERM) 2-3, 5-22
F
fabric, ServerNet 4-4
factory-installed hardware,
documentation 4-23
failure recovery 4-8
fan
NonStop Blade Element 5-7
OAM enclosure 5-16
p-switch 5-13
FCSA
configuration recommendations 6-21
FCSA to FCDM cabling 6-23
FCSA to tape cabling 6-15
FC-AL configuration
recommendations 6-21
fiber-optic cable specifications 6-5
fiber-optic cables 6-3
Fibre Channel arbitrated loop (FC-
AL) 5-20, 6-20
Fibre Channel device considerations 6-20
Fibre Channel devices 6-18
Fibre Channel disk module 5-20, 6-18
Fibre Channel ServerNet adapter
(FCSA) 5-18
flooring 2-5
