Enclosure Power Loads
enclosures installed. For examples of calculating the power and current load for
various enclosure combinations, refer to Calculating Specifications for Enclosure
Combinations on page 3-11.
In normal operation, the AC power is split equally between the two PDUs in the
modular cabinet. However, if one of the two AC power feeds fails, the remaining AC
power feed and PDU must carry the power for all enclosures in that cabinet.
Power and current specifications for each type of enclosure are:
Enclosure Type
AC Power
Lines per
Enclosure
1
Apparent Power
(volt-amps
measured on
single AC line
with one line
powered)
Apparent Power
(volt-amps
measured on
single AC line
with both lines
powered)
6
Peak
Inrush
Current
(amps)
4-processor NonStop
Blade Element:
16 GB memory boards
32 GB memory boards
2
2
680
710
Per line:
380
390
Total:
760
780
17
17
LSU (with four LSUs) 2 150 110 220 67
Processor switch
2
2 160 100 200 5
IOAM enclosure
3
4 420 250 500 68
Fibre Channel disk
module
4
2 220 140 280 14
Maintenance switch
(Ethernet)
5
150 - 4
1
Half of the plugs for an enclosure must be connected to the right-side PDU and the other half connected to the
left-side PDU. PDUs must be supplied from separate branch circuits.
2
Measured with three PICs installed and active,
3
Measured with 10 Fibre Channel ServerNet adapters installed and active.
4
Measured with 14 disk drives installed and active.
5
Maintenance switch has only one plug. This plug must be connected to the right-side PDU (the PDU that is
supplied by a UPS, if installed).
6
Total apparent power is the sum of the two AC power lines feeding the enclosure. Electrical load is shared
equally between the two lines.
