System Installation Specifications
HP Integrity NonStop NS-Series Planning Guide—529567-005
3-7
Service Clearances for the Modular Cabinet
Service Clearances for the Modular Cabinet
Aisles: 6 feet (182.9 centimeters)
Front: 3 feet (91.4 centimeters)
Rear: 3 feet (91.4 centimeters)
Unit Sizes
Modular Cabinet PDU Keepout Panel
PDU keepout applies only when the PDU junction boxes reside at the bottom of the
modular cabinet. PDUs overlap the outside of the rack by 2 U (3.5 inches). A PDU
keepout panel is installed in affected space when:
•
1U keepout applies when a UPS occupies the bottom position of the modular
cabinet.
•
2U keepout applies when a NonStop Blade Element occupies the bottom position
of the modular cabinet.
Enclosure Type Height (U)
Modular cabinet 42
NonStop Blade Element 5
Processor switch 3
LSU 4
IOAM 11
Disk drive 3
Maintenance switch (Ethernet) 1
R5500 XR UPS 3
Extended runtime module 3
PDU keepout panel
*
1 or 2
*
Rackmount console 2
*
See Modular Cabinet PDU Keepout Panel.
