Modular Cabinet Physical Specifications
Modular Cabinet Physical Specifications
Enclosure Dimensions
Item Height Width Depth Weight
in. cm in. cm in. cm
Modular cabinet 78.5 199.4 23.5 59.7 44.0 111.8 Depends on the
enclosures installed.
Refer to Modular
Cabinet and
Enclosure Weights
With Worksheet on
page 3-9.
Rack 78.5 199.4 23.5 59.7 40.0 101.9
Front door 78.5 199.4 23.5 59.7 3.0 7.6
Left-rear door 78.5 199.4 11.0 27.9 1.0 2.5
Right-rear door 78.5 199.4 12.0 30.5 1.0 2.5
Shipping
(palletized)
83.5 212.0 39.0 99.0 48.0 121.9
Enclosure Type
Height Width Depth
in cm in cm in cm
NonStop Blade Element 8.8 22.2 19.0 48.3 27.0 68.6
Processor switch 5.3 13.3 19.0 48.3 24.5 62.2
LSU 7.0 17.9 19.0 48.3 27.0 68.6
IOAM 19.25 48.9 19.0 48.3 27.0 68.6
Disk drive 5.2 13.1 19.9 50.5 17.6 44.8
Maintenance switch (Ethernet) 1.8 4.6 17.4 44.2 8.0 20.3
Rackmount console system unit
Keyboard and display
1.7 4.3 16.8 42.7 24.0 60.9
1.7 4.3 15.6 39.6 17.0 43.2
X5500 XR UPS 5.1 13.0 17.5 44.5 26.0 66.0
Extended runtime module (ERM) 5.1 13.0 17.5 44.5 25.1 63.8
PDU keepout panel
*
3.5 8.9 -- -- -- --
*
See Modular Cabinet PDU Keepout Panel on page 3-7.
