System Installation Specifications
HP Integrity NonStop NS-Series Planning Guide—529567-005
3-9
Modular Cabinet and Enclosure Weights With
Worksheet
Modular Cabinet and Enclosure Weights With Worksheet
The total weight of each modular cabinet is the sum the weights of the cabinet plus
each enclosure installed in it. Use this worksheet to determine the total weight:
For examples of calculating the weight for various enclosure combinations, refer to
Calculating Specifications for Enclosure Combinations on page 3-11.
Environmental Specifications
Enclosure Type
Number of
Enclosures
Weight Total
lbs kg lbs kg
Modular cabinet
*
370 167.8
NonStop Blade Element 112 50.8
Processor switch 70 32.8
LSU 96 43.5
IOAM 200 90.7
Disk drive 78 35.4
Maintenance switch (Ethernet) 6 2.7
Rackmount console system unit
Keyboard and display
37 16.8
X5500 XR UPS 160 72.6
Extended runtime module
(ERM)
170 77.1
Total -- --
*
Modular cabinet weight includes the PDUs and their associated wiring and receptacles.
Topic Page
Heat Dissipation Specifications and Worksheet 3-10
Operating Temperature, Humidity, and Altitude 3-10
Nonoperating Temperature, Humidity, and Altitude 3-11
Cooling Airflow Direction 3-11
Typical Acoustic Noise Emissions 3-11
Tested Electrostatic Immunity 3-11
