System Installation Specifications
HP Integrity NonStop NS-Series Planning Guide—529567-005
3-10
Heat Dissipation Specifications and Worksheet
Heat Dissipation Specifications and Worksheet
Operating Temperature, Humidity, and Altitude
Enclosure Type
Number
Installed
Unit Heat
(Btu/hour
with single
AC line
powered)
Unit Heat
(Btu/hour
with both
AC lines
powered)
Total
(BTU/hour)
4-processor NonStop Blade
Element:
16 GB memory boards
32 GB memory boards
2320
2423
2594
2662
LSU (with four LSUs) 512 750
Processor switch
1
546 682
IOAM
2
1433 1706
Disk drive
3
751 956
Maintenance switch (Ethernet)
4
171 -
Rackmount console system unit
Keyboard and display
1194 -
171 -
1
Measured with three PICs installed and active,
2
Measured with 10 Fibre Channel ServerNet adapters installed and active.
3
Measured with 14 disk drives installed and active.
4
Maintenance switch has only one plug. This plug must be connected to the right-side PDU (the PDU that is
supplied by a UPS, if installed).
Specification Operating Range
1
Recommended
Range
1
Maximum Rate of Change
per Hour
Temperature (all
except Fibre
Channel disk
module)
41° to 95° F
(5° to 35° C)
68° to 72° F
(20° to 25° C)
9° F (5° C) Repetitive
36° F (20° C) Nonrepetitive
Temperature (Fibre
Channel disk
module)
50° to 95° F
(10° to 35° C)
-0.6° F (1° C) Repetitive
1.6° F (3° C) Nonrepetitive
Humidity 15% to 80%,
noncondensing
40% to 50%,
noncondensing
6%, noncondensing
Altitude
2
0 to 10,000 feet
(0 to 3,048 meters)
--
1. Operating and recommended ranges refer to the ambient air temperature and humidity measured 19.7 in.
(50 cm) from the front of the air intake cooling vents.
2. For each 1000 feet (305 m) increase in altitude above 10,000 feet (up to a maximum of 15,000 feet), subtract
1.5° F (0.83° C) from the upper limit of the operating and recommended temperature ranges.
