System Installation Specifications
HP Integrity NonStop NS-Series Planning Guide—529567-005
3-12
Calculating Specifications for Enclosure
Combinations
This duplex configuration has 16 logical processors with two IOAM enclosures, 14
Fibre Channel disk modules, and three cabinets. The load for cabinet one is:
The load for cabinet two is:
Component Quantity
Height
(U)
Weight
(lbs)
Weight
(kg)
Volt-amps
per AC feed,
one feed
powered
Volt-amps
per AC feed,
both feeds
powered
Heat
(Btu)
NonStop
Blade
Element
3 15 336 152.4 2130 1170 7986
LSU 1 4 96 43.5 150 110 750
Processor
switch
2 6 140 65.6 320 200 2728
IOAM
enclosure
1 11 200 90.7 420 250 1706
Fibre
Channel disk
module
----- - -
Console - - - - - - -
Maint. switch 1 1 6 2.7 0.2 - 171
Cabinet 1 42 370 167.8 - - -
Total - 37 1148 522.7 3020.2 1730 13341
Component Quantity
Height
(U)
Weight
(lbs)
Weight
(kg)
Volt-amps
per AC feed,
one feed
powered
Volt-amps
per AC feed,
both feeds
powered
Heat
(Btu)
NonStop
Blade
Element
3 15 336 152.4 2130 1170 7986
LSU 1 4 96 43.5 150 110 750
Processor
switch
----- - -
IOAM
enclosure
----- - -
Fibre
Channel disk
module
7 21 546 247.8 1540 980 6692
Console 1 2 37 16.8 2.3 - 1365
Maintenance
switch
----- - -
Cabinet 1 42 370 167.8 - - -
Total - 42 1385 628.3 3822.3 2260 16793
