Integrity NonStop NS-Series System Description
HP Integrity NonStop NS-Series Planning Guide—529567-005
4-19
Default Startup Characteristics
°
In NonStop S-series I/O enclosure group, module, slot 11.1.11
•
Configured system load paths
•
Enabled command interpreter input (CIIN) function
If the automatic system load is not successful, additional paths for loading are available
in the boot task. Using one load path, the system load task attempts to use another
path and keeps trying until all possible paths have been used or the system load is
successful. These 16 paths are available for loading, in their order of use:
Load Path Description Source Disk
Destination
Processor
ServerNet Fabric
1 Primary $SYSTEM-P 0 X
2 Primary $SYSTEM-P 0 Y
3 Backup $SYSTEM-P 0 X
4 Backup $SYSTEM-P 0 Y
5 Mirror $SYSTEM-M 0 X
6 Mirror $SYSTEM-M 0 Y
7 Mirror backup $SYSTEM-M 0 X
8 Mirror backup $SYSTEM-M 0 Y
9 Primary $SYSTEM-P 1 X
10 Primary $SYSTEM-P 1 Y
11 Backup $SYSTEM-P 1 X
12 Backup $SYSTEM-P 1 Y
13 Mirror $SYSTEM-M 1 X
14 Mirror $SYSTEM-M 1 Y
15 Mirror backup $SYSTEM-M 1 X
16 Mirror backup $SYSTEM-M 1 Y
