Integrity NonStop NS-Series System Description
HP Integrity NonStop NS-Series Planning Guide—529567-005
4-24
Factory-Installed Hardware Configuration Tech
Memo
This document is an example only and will not be the same as the one included with
your system.
VST.604.vsd
Rear U # Source
Label
Node-Rack-TypeEnc-S-P Cable P/N Destination
Label
Node-Rack-TypeEnc-S-P Rack-U #
41-42
40 PWR CORD:12A,C20-C13,0.68M
528776-001
outlets : 14
40 TSI #T1200 Serial N1-R1-U40-SER
40 TSI #T1200 SCSI :1 N1-R1-U40-SCSI-1
529789-001
LTO Tape Drive : Port 2
40 TSI #T1200 SCSI :0 N1-R1-U40-SCSI-0
529789-001
LTO Tape Drive : Port 1
40 TSI #T1200 Fibre Ch Port N1-R1-U40-FC 522745-002
IOAME1 : FCSA 3.2: 1
N1-R1-U23-3-2-1 29
39
PRIMARY JBOD 1 : FC-AL A1
N1-R1-U37-A-1
39
PRIMARY JBOD 1 : FC-AL B1
N1-R1-U37-B-1 522745-002
IOAME1 : FCSA 2.1: 1
N1-R1-U23-2-1-1 29
37 PRIMARY JBOD 1 : FC-AL A2 N1-R1-U37-A-2 522745-002 IOAME1 : FCSA 3.1: 1 N1-R1-U23-3-1-1 29
37 PRIMARY JBOD 1 : FC-AL B2 N1-R1-U37-B-2
37 PWR CORD : 12A, C20-13, 0.84M 528775-001 outlets : 13
36 MIRRROR JBOD 1 : FC-AL A1 N1-R1-U34-A-1
36 MIRROR JBOD 1 : FC-AL B1 N1-R1-U34-B-1 522745-002 IOAME1 : FCSA 2.1: 2 N1-R1-U23-2-1-2 29
34
MIRROR JBOD 1 : FC-AL A2
N1-R1-U34-A-2 522745-002
IOAME1 : FCSA 3.1: 2
N1-R1-U23-3-1-2 29
34
MIRROR JBOD 1 : FC-AL B2
N1-R1-U34-B-2
34
PWR CORD : 12A, C20-13, 0.84M
528775-001 outlets : 12
IOAME1 : 2.14 : 10/100 ENET
N1-R1-U23-2.14-E U23148-A00 Maint Switch : Ethernet 4 N1-R1-U1-4 1
IOAME1 : 2.14 : 1
N1-R1-U23-2.14-1 522745-002
P-Switch X : Slot 4 : 1
N1-R1-U17-4-1 17
IOAME1 : 2.14 : 2
N1-R1-U23-2.14-2 522745-002
P-Switch X : Slot 4 : 2
N1-R1-U17-4-2
IOAME1 : 2.14 : 3
N1-R1-U23-2.14-3 522745-002
P-Switch X : Slot 4 : 3
N1-R1-U17-4-3
IOAME1 : 2.14 : 4 N1-R1-U23-2.14-4 522745-002 P-Switch X : Slot 4 : 4 N1-R1-U17-4-4 19
IOAME1 : 3.14 : 10/100 ENET N1-R1-U23-3.14-E U23148-A00 Maint Switch : Ethernet 3 N1-R1-U1-3 1
IOAME1 : 3.14 : 1 N1-R1-U23-3.14-1 522745-002 P-Switch Y : Slot 4 : 1 N1-R1-U20-4-1 20
IOAME1 : 3.14 : 2 N1-R1-U23-3.14-2 522745-002 P-Switch Y : Slot 4 : 2 N1-R1-U20-4-2
IOAME1 : 3.14 : 3
N1-R1-U23-3.14-3 522745-002
P-Switch Y : Slot 4 : 3
N1-R1-U20-4-3
IOAME1 : 3.14 : 4
N1-R1-U23-3.14-3 522745-002
P-Switch Y : Slot 4 : 4
N1-R1-U20-4-4 22
30-31
IOAME1 : FCSA 3.2: 1
N1-R1-U23-3-2-1 522745-002
M8201
(
TSI T1200
)
Fibre Ch Port N1-R1-U40-FC 40
IOAME1 : FCSA 3.2: 2
IOAME1 : FCSA 3.1: 1
N1-R1-U23-3-1-1 522745-002
PRIMARY 1 JBOD : FC-AL A2
N1-R1-U37-A-2 37
IOAME1 : FCSA 3.1: 2
N1-R1-U23-3-1-2 522745-002
MIRROR 1 JBOD : FC-AL A2
N1-R1-U34-A-2 34
IOAME1 : FCSA 2.1: 1 N1-R1-U23-2-1-1 522745-002 PRIMARY 1 JBOD : FC-AL B1 N1-R1-U37-B-1 39
IOAME1 : FCSA 2.1: 2 N1-R1-U23-2-1-2 522745-002 MIRROR 1 JBOD : FC-AL B1 N1-R1-U34-B-1 36
IOAME1 : G4SA 2.5: A N1-R1-U23-2-5-A
IOAME1 : G4SA 2.5: B N1-R1-U23-2-5-B
IOAME1 : G4SA 2.5: C N1-R1-U23-2-5-C
IOAME1 : G4SA 2.5: D
N1-R1-U23-2-5-D
24-26
PWR CORD : 12A, C20-13, 0-84M 528775-001
outlets : 10
PWR CORD : 12A
,
C20-13
,
0-84M 528775-001
outlets : 9
22 PWR CORD : 12A, C20-13, 0-84M 528775-001 outlets : 8
P-Switch Y : Slot 1 : ENET
(
3
)
N1-R1-U20-1-3 U23148-A00
Maint Switch : Ethernet 2
N1-R1-U1-2 1
P-Switch Y : Slot 10 : 4
N1-R1-U20-10-4 522745-002
LSUE 0 : Slot 23 : SNet
Y
N1-R1-U13--23-
Y
16
P-Switch Y : Slot 4 : 4
N1-R1-U20-4-4 522745-002
IOAME1 : 3.14 : 4
N1-R1-U23-3.14-4 32
P-Switch Y : Slot 10 : 3
N1-R1-U20-10-3 522745-002
LSUE 0 : Slot 22 : SNet Y
N1-R1-U13-22-Y 16
P-Switch Y : Slot 4 : 3
N1-R1-U20-4-3 522745-002
IOAME1 : 3.14 : 3
N1-R1-U23-3.14-3 32
P-Switch Y : Slot 10 : 2
N1-R1-U20-10-2 522745-002
LSUE0 : Slot 21 : SNet
Y
N1-R1-U13-21-Y 16
P-Switch Y : Slot 4 : 2 N1-R1-U20-4-2 522745-002 IOAME1 : 3.14 : 2 N1-R1-U23-3.14-2 32
P-Switch Y: Slot 3 : 2 N1-R1-U20-3-2 522745-002 P-Switch X : Slot 3 : 1 N1-R1-U17-3-1 17
P-Switch Y : Slot 10 : 1 N1-R1-U20-10-1 522745-002 LSUE 0 : Slot 20 : SNet Y N1-R1-U13-20-Y 16
P-Switch Y : Slot 4 : 1
N1-R1-U20-4-1 522745-002
IOAME1 : 3.14 : 1
N1-R1-U23-3.4-1 32
P-Switch Y : Slot 3 : 1
N1-R1-U20-3-1 522745-002
P-Switch X : Slot 3 : 2
N1-R1-U17-3-2 18
P-Switch Slot 1: SER (1)
N1-R1-U20-1-1
console
?
19 PWR CORD : 12A, C20-13, 0-84M 528775-001 outlets : 7
P-Switch X : Slot 1 : ENET
(
3
)
N1-R1-U17-1-3 U23148-A00
Maint Switch : Ethernet 1
N1-R1-U1-1 1
P-Switch X : Slot 10 : 4
N1-R1-U17-10-4 522745-002
LSUE 0 : Slot 23 : SNet
X
N1-R1-U13--23-
X
16
P-Switch X : Slot 4 : 4
N1-R1-U17-4-4 522745-002
IOAME1 : 2.14 : 4
N1-R1-U23-2.14-4 33
P-Switch X : Slot 10 : 3
N1-R1-U17-10-3 522745-002
LSUE 0 : Slot 22 : SNet X
N1-R1-U13-22-X 16
P-Switch X : Slot 4 : 3
N1-R1-U17-4-3 522745-002
IOAME1 : 2.14 : 3
N1-R1-U23-2.14-3 33
P-Switch X : Slot 10 : 2
N1-R1-U17-10-2 522745-002
LSUE0 : Slot 21 : SNet
X
N1-R1-U13-21-X 16
P-Switch X : Slot 4 : 2
N1-R1-U17-4-2 522745-002
IOAME1 : 2.14 : 2
N1-R1-U23-2.14-2 33
P-Switch X : Slot 3 : 2
N1-R1-U17-3-2 522745-002
P-Switch Y : Slot 3 : 1
N1-R1-U20-3-1 20
P-Switch X : Slot 10 : 1 N1-R1-U17-10-1 522745-002 LSUE 0 : Slot 20 : SNet
X
N1-R1-U13-20-
X
16
P-Switch X : Slot 4 : 1 N1-R1-U17-4-1 522745-002 IOAME1 : 2.14 : 1 N1-R1-U23-2.4-1 33
P-Switch X : Slot 3 : 1 N1-R1-U17-3-1 522745-002 P-Switch Y: Slot 3 : 2 N1-R1-U20-3-2 21
P-Switch Slot 1: SER (1)
N1-R1-U17-1-1
console
?
20
19
18
17
27
23
22
21
29
33
18
32
21
Exam ple Tech M em o for D uplex P rocessor S ystem (Sheet 1 of 2)
