Integrity NonStop NS-Series System Description
HP Integrity NonStop NS-Series Planning Guide—529567-005
4-25
ServerNet Adapter Configuration Forms
ServerNet Adapter Configuration Forms
ServerNet adapters can include the Fibre Channel ServerNet adapter (FCSA) and
Gigabit Ethernet 4-port ServerNet adapter (G4SA) that are installed exclusively in the
Integrity NonStop NS-series system or the various ServerNet adapters installed in the
NonStop S-series I/O enclosures that are connected to the system.
To add ServerNet adapter configuration forms to your Installation Document Packet,
copy the necessary forms from the adapter manuals. Follow any planning instructions
in the adapter manuals.
For supported ServerNet adapters, see NonStop NS-Series Supported Hardware.
ServerNet Cluster Configuration Form
The configuration form for installing a ServerNet cluster is located in the ServerNet
Cluster Manual.
Example Tech Memo for Duplex Processor System (Sheet 2 of 2)
LSUE 0 : Slot 20 : SNet Y
N1-R1-U13-20-Y 522745-002
P-Switch Y : Slot 10 : 1
N1-R1-U20-10-1 20
LSUE 0 : Slot 20 : SNet X
N1-R1-U13-20-X 522745-002
P-Switch X : Slot 10 : 1
N1-R1-U17-10-1 17
LSUE 0 : Slot 21 : SNet Y
N1-R1-U13-21-Y 522745-002
P-Switch Y : Slot 10 : 2
N1-R1-U20-10-2 21
LSUE 0 : Slot 21 : SNet X
N1-R1-U13-21-X 522745-002
P-Switch X : Slot 10 : 2
N1-R1-U17-10-2 18
LSUE 0 : Slot 22 : SNet Y
N1-R1-U13-22-Y 522745-002
P-Switch Y : Slot 10 : 3
N1-R1-U20-10-3 21
LSUE 0 : Slot 22 : SNet X
N1-R1-U13-22-X 522745-002
P-Switch X : Slot 10 : 3
N1-R1-U17-10-3 18
LSUE 0 : Slot 23 : SNet Y
N1-R1-U13-23-Y 522745-002
P-Switch Y : Slot 10 : 4
N1-R1-U20-10-4 22
LSUE 0 : Slot 23 : SNet X
N1-R1-U13-23-X 522745-002
P-Switch X : Slot 10 : 4
N1-R1-U17-10-4 19
LSUE 0 : Slot 20 : Strand B
N1-R1-U13-20-B 522745-002 N1-R1-U8-71-J0
LSUE 0 : Slot 21 : Strand B
N1-R1-U13-21-B 522745-002 N1-R1-U8-71-J1
LSUE 0 : Slot 22 : Strand B
N1-R1-U13-22-B 522745-002 N1-R1-U8-72-J2
LSUE 0 : Slot 23 : Strand B
N1-R1-U13-23-B 522745-002 N1-R1-U8-72-J3
LSUE 0 : Slot 20 : Strand A
N1-R1-U13-20-A 522745-002 N1-R1-U3-71-J0
LSUE 0 : Slot 21 : Strand A N1-R1-U13-21-A 522745-002 N1-R1-U3-71-J1
LSUE 0 : Slot 22 : Strand A N1-R1-U13-22-A 522745-002 N1-R1-U3-72-J2
LSUE 0 : Slot 23 : Strand A N1-R1-U13-23-A 522745-002 N1-R1-U3-72-J3
13 PWR CORD : 12 A, C20-13, 0-68M 528776-001 outlets : 5
N1-R1-U8-80-S 529284-001 N1-R1-U3-80-Q
N1-R1-U8-80-T 529284-001 N1-R1-U3-80-R
N1-R1-U8-80-Q 529284-001 N1-R1-U3-80-S
N1-R1-U8-80-R 529284-001 N1-R1-U3-80-T
11
N1-R1-U8-72-J3 522745-002
LSUE 0 : Slot 23 : Strand B
N1-R1-U13-23-B
N1-R1-U8-72-J2 522745-002
LSUE 0 : Slot 22 : Strand B
N1-R1-U13-22-B
N1-R1-U8-71-J1 522745-002
LSUE 0 : Slot 21 : Strand B
N1-R1-U13-21-B
N1-R1-U8-71-J0 522745-002
LSUE 0 : Slot 20 : Strand B
N1-R1-U13-20-B
8 N1-R1-U8-0-SER
?
8
PWR CORD : 12 A, C20-13, 2.0M
528777-001 outlets : 3
N1-R1-U3-80-S 529284-001 N1-R1-U8-80-Q
N1-R1-U3-80-T 529284-001 N1-R1-U8-80-R
N1-R1-U3-80-Q 529284-001 N1-R1-U8-80-S
N1-R1-U3-80-R 529284-001 N1-R1-U8-80-T
6 6
N1-R1-U3-72-J3 522745-002
LSUE 0 : Slot 23 : Strand A
N1-R1-U13-23-A
N1-R1-U3-72-J2 522745-002
LSUE 0 : Slot 22 : Strand A
N1-R1-U13-22-A
N1-R1-U3-71-J1 522745-002
LSUE 0 : Slot 21 : Strand A
N1-R1-U13-21-A
N1-R1-U3-71-J0 522745-002
LSUE 0 : Slot 20 : Strand A
N1-R1-U13-20-A
3 N1-R1-U3-0-SER
console
?
3
PWR CORD : 12 A, C20-13, 2.0M
528777-001 outlets : 2
2U
Maint Switch : Ethernet 4
N1-R1-U1-4 U23148-A00
IOAME : 2.14 : 10/100 ENET
N1-R1-U23-2.14-E 33
Maint Switch : Ethernet 3
N1-R1-U1-3 U23148-A00
IOAME : 3.14 : 10/100 ENET
N1-R1-U23-3.14-E 32
Maint Switch : Ethernet 2
N1-R1-U1-2 U23148-A00
P-Switch Y : Slot 1 : ENET (3)
N1-R1-U20-3-1-3 22
Maint Switch : Ethernet 1
N1-R1-U1-1 U23148-A00
P-Switch X : Slot 1 : ENET (3)
N1-R1-U17-2-1-3 19
PWR CORD : 12A, C20-13, 0.68M
528776-001 outlets : 1
12
14
9-10U
7
7
4-5 14
1
16
4-5
7
12
9-10U 14
12
VST605.vsd
NSBE 1B : Slot 72 : J3
NSBE 1B : Slot 72 : J2
NSBE 1B : Slot 71 : J1
NSBE 1B : Slot 71 : J0
NSBE 1B, Serial
NSBE 1A : Slot 80: S
NSBE 1A : Slot 80: T
NSBE 1A : Slot 80: Q
NSBE 1 A : Slot 80: R
NSBE 1A : Slot 72 : J3
NSBE 1A : Slot 72 : J2
NSBE 1A : Slot 71 : J1
NSBE 1A : Slot 71 : J0
NSBE 1A, Serial
NSBE 1B : Slot 71 : J0
NSBE 1B : Slot 71 : J1
NSBE 1B : Slot 72 : J2
NSBE 1B : Slot 72 : J3
NSBE 1A : Slot 71 : J0
NSBE 1A : Slot 71 : J1
NSBE 1A : Slot 72 : J2
NSBE 1A : Slot 72 : J3
NSBE 1A : Slot 80: Q
NSBE 1 A : Slot 80: R
NSBE 1A : Slot 80: S
NSBE 1A : Slot 80: T
console
NSBE 1B : Slot 80: Q
NSBE 1B : Slot 80: R
NSBE 1B : Slot 80: S
NSBE 1B : Slot 80: T
NSBE 1B : Slot 80: S
NSBE 1B : Slot 80: T
NSBE 1B : Slot 80: Q
NSBE 1B : Slot 80: R
